3. BASIC OPERATION

3.1 Installing the Battery

The CamView IP Pro, Pro-C, and Pro+ use a rechargeable lithium-ion polymer battery. To ensure
safety when transporting, always disconnect the battery from the tester. The device may leave the
factory with one of the following two battery placements:
• The battery is placed inside tester and insulated from the contacts with a thin, plastic sheet.
In this case, the user should open the battery cover, take out the battery, remove the plastic
sheet, then put the battery back in, and put the battery cover back on.
• The battery is placed outside the tester. In this case, the user should open the battery cover,
put the battery securely into the battery compartment, and put the battery cover back on.
Note — The tester will automatically turn on when the battery is properly placed in the device for
the first time.

3.2 Charging the Battery

Be sure to fully charge the battery prior to first use. If the battery level is too low, the charge indica-
tor will flash 3 times, and the device won't turn on.
You should use the POE injector and ethernet cable provided by the manufacturer to charge the
battery. To charge the unit, connect one end of the ethernet cable to the Data/Power-out Port on
the POE Injector, then connect the other end of the ethernet cable to the Network Port 2 (Green
outline) on the tester. Once you have connected the ethernet cable on both ends, plug in the pow-
er cord for the POE Injector into a power outlet. Network Port 2 will light up with an orange light
when the internal battery is recharging.
3.3 Frequently Asked Questions About the Battery
• The CamView IP Pro, Pro-C, and Pro+ use a lithium-ion polymer battery, which does not
have a memory effect. Users can recharge the battery whenever they want.
• When recharging, the Charge Indicator on the tester will light up red. When the battery is
fully charged, the light will turn off.
• Due to calculation deviation or other reason, the battery level can be as low as 90% when
the charge light turns off. Users can ensure their battery Is fully charged by extending the
charge time for up to 60 minutes.
