CamView IP Pro, Pro-C, and Pro+ User Manual
LIST SUBNET:
To use the List Subnet function, IP and Mask should be set up, and the Subnet Mask should
be 24bits wide (subnet size of 256 devices, or 8 bits). Refer to the instructions on page 29 if
you need to update the IP, Subnet Mask, or Gateway.
While you are on the Network Tools screen, press
The Tester will then scan the whole subnet. Devices being scanned must reply, so the
discover rate is 100% if the device is operating normally. This List Subnet function will also
measure the network latency, and display it in ms (milliseconds).
The List Subnet display format is: XX-XX-XX-XX -XX-XX I.I.I.I N ms. Where XX is the MAC
address displayed in HEX, Iis the IP address displayed in decimal, and N is the network
latency.
Compared to the network sniff function, this function cannot detect devices with different
Subnet settings, but the same Subnet detection rate is 100%.
The List Subnet will take 1-10 seconds to finish. Press
function.
PING TEST:
To use the Ping Test, IP, Subnet Mask, and Destination must be filled in. If the destination is
a domain, then DNS/Gateway are also needed. Refer to the instructions on page 29 if you
need to update the IP, Subnet Mask, or DNS/Gateway.
Use the Flip Keyboard when the destination section is yellow to edit the Destination.
While you are on the Network Tools screen, press
The ping test displays result in chart form as shown on page 32. The first column is the
latency grade; the second column is the number of responses at that latency grade; the third
column is the respond time percentage; and the fourth column is the latency chart.
Zoom+
Press to exit the Ping Test.
Focus-
to run the List Subnet function.
Focus-
to exit the List Subnet
Zoom+
to run the Ping Test.
31
