Triplett CamView IP Pro User Manual page 21

Link Speed of Corresponding Port — The Link Speed displays above the bar icon.
41
shows for each Port. The link speed can also be observed via the icon itself.
• If the bar icon is gray, there is no network connection. It will also say "Link
• If the bar icon is white, the tester is sensing and will display the link speed
Ethernet Data Flow Monitor — shows the current Ethernet traffic flow.
42
• ¡ is the outgoing data flow in b/s, Kbps, and Mbps.
• ¢ is the incoming data flow in b/s, Kbps, and Mbps.
Packet Loss Monitor — The displayed data shows the success rate. Normally this
43
number is 100%. The color of the bars will differ according to the success rate.
• Gray Bars — No Link
• Green Bars — 100% of packet transfers successfully completed
• Yellow Bars — 99%+ of packet transfers successfully completed
• Orange Bars — 95% - 99% of packet transfers completed
• Red Bars — Less than 95% of packet transfers completed
POE Power Supply Status — This icon is for Network Port 1 and indicates the POE
44
power output status.
The first line of text is output mode:
45
• 12V — The device is outputting 12V and detecting PD at the same time.
• PD. CLAS — The classification of the remote POE device.
• PSE 48V — The remote POE device is being powered by the Tester.
The second line of text shows the output power in Watts. When outputting power, the
actual power consumption is decided by the remote device. The tester has a max power
limit. When the remote device requires more power than max power, the output will
terminate automatically.
POE Power Accept Status — This icon applies to network port 2, indicating the POE
46
power acceptance status. The text displays the powering voltage as measured by the
Tester. (E.g., PSE 48V — The Tester is being provided with POE at 48V.)
CamView IP Pro, Pro-C, and Pro+ User Manual
Down" as shown in the sample image.
(10M/100M/1000M) and whether the connection is Full or Half Duplex.
(i.e., up to 1% - 5% packet loss)
(i.e., 5% - 99% packet loss)
17
