4.3.3 Using the Analog Camera Test Interface
Once you have connected the Analog Camera to the Tester and set up the camera's power supply,
follow these steps to perform Analog Camera testing:
STEP 1: Power Up the Tester
Press the Power Button on the side of your CamView IP Pro, Pro-C, or Pro+ Tester to turn it on if
it is not already powered on.
STEP 2: Select Analog Camera Test
On the Main Menu, highlight "Analog Camera Test" using the Down Arrow Key. Once the "Analog
Camera Test" option is highlighted, press the Right Arrow Key to select the test.
Live video will show in the video display area. Due to varying image aspect ratios, the displayed
image may not be full screen and some parts of the screen may be black (e.g., on the left and right
side).
The signal information will show in the upper right of the screen, and will display the Format (e.g.,
NTSC, HD-TVI, etc.), and the resolution (e.g., 720x480), framerate (e.g., 30fps), and signal level.
STEP 3: Testing PTZ
While you are on the Analog Camera Test screen, you will notice the On-Screen Instructions give
you the following options:
RECORDING SCREEN SHOTS AND SAMPLE VIDEOS:
Press the A Key to save a Screen Shot to the Tester's internal flash memory, or press the Z
Key to record video to the Tester's internal flash memory.
DIGITAL ZOOM:
Opening the flip-keyboard and pressing the 1 or Q Keys will allow you to digitally zoom in
and out.
PAN AND TILT:
Press the Arrow Keys or
functions on the camera. When the Tester is sending a Pan/Tilt signal to the camera, the
Data Transmission Indicator on the top left of the Tester's display will light up red. If you
see that icon light up but do not see any movement on the camera, you will need to adjust
the Tester's settings to match the camera's requirements regarding Protocol (e.g., Pelco D),
Baud Rate (e.g., 2400), etc. The camera's factory default settings should be in the camera's
user manual.
CamView IP Pro, Pro-C, and Pro+ User Manual
Focus +/-, Zoom +/-, and Iris +/-
to test the Pan, Tilt, Zoom
