Triplett CamView IP Pro User Manual page 19

For example, if the camera's IP address is 10.1.1.100, you would enter that into the "URL"
field and then press the TAB Key. The Tester should then automatically append the
IP address to include ".../onvif/device_service" at the end of the original 10.1.1.100 address.
The final result will look like this: http://10.1.1.100/onvif/device_service.
Iris+
Press to accept the settings and return to the Discover screen.
You may also notice the Discover screen has a different set of On-Screen Options than what was
on the Link Test screen, including Rediscover (which will run by pressing Focus-), Manual Add
(accessible by pressing Zoom-), Refresh Pic (which will snap a new image from the camera by
pressing Iris-), and so forth. Take a few minutes to review the On-Screen Options as you explore
each screen.
STEP 5: Selecting and Accessing the Camera
Once you have highlighted the camera you want to test on the Discover screen, press the RIGHT
ARROW Key to select that camera.
If the camera requires a Username and Password, a notice will display on the right side of the
screen saying "Authorization Required". In this case, you will need to press
Username/Password screen. You can then open the flip keyboard to fill in the Username and
Password (use the TAB Key to move between the fields, then press the RETURN Key when you
are done).
Once you have accessed the camera, a snapshot from the camera will appear on the right side
of the Discover screen. Information about the camera's resolution, framerate, and compression
method will show above the snapshot (see picture below).
CamView IP Pro, Pro-C, and Pro+ User Manual
Iris-
to access the
Continued on page 18.
15
