APPENDIX 2: TECHNICAL SPECIFICATIONS

PORTS
Network Ports
I/O Ports
IP CAMERA TEST FEATURES
Protocols
Ethernet Tests
IP Configurations
IP Camera Tests
AHD, TVI, HD-CVI, & SD ANALOG CAMERA TEST FEATURES
SD Signal Format
HD Video Signal Formats AHD & TVI (Pro+ model only); HD-CVI (Pro-C model only)
Resolutions
Signal Level
Camera Tests
PTZ CONTROLS
Protocol
Baud Rate
DETECTION
TDR Tests
PTZ Test
POE Tests
Network Analysis
Analog Video Generator Generate PAL / NTSC video signals of various test patterns
Record Playback
CamView IP Pro, Pro-C, and Pro+ User Manual
(2) 10M/100M/1G RJ45 ports (Blue is POE Out; Green is POE In)
(2) BNC ports (Video IN and Video OUT), (1) RS485, (1) Audio In, (1) USB, (1) Reset Button
ONVIF 2.4.1, RTSP, RTP
10M/100M/1G Ethernet link test, loop detect, Ethernet traffic flow monitor, link quality
test
Static IP / DHCP client / DHCP server
Discover camera, real-time video, camera configuration, PTZ control, audio test, full screen
preview, and 8x digital zoom; snapshot, record video (recording original data stream),
store ONVIF camera reports
NTSC / PAL
D1, 720P, 1080P
1Vpp
Real-time video, PTZ control, audio test, full-screen preview, and 8x digital zoom;
snapshot, record video (H.264)
More than 30 protocols including Dahua, Pelco-D/P, Samsung, Panasonic, Lilin, Yaan etc.
150, 300, 600, 1200, 2400, 4800, 9600, 19200bps
0~150m network cable length measurement (resolution 1m), cable pair status
Data Monitor to detect RS485 Communication from control room console to camera
PD test (tester accepts POE power, displays voltage)
PSE test (tester provides POE power, displays power)
Sniff, list subnet, ping
Support local playback of recorded video and view screenshots
