Cable requirements
For proper operation, adhere to the following cable and power
requirements for the cameras. Category 5 cabling or better is
recommended. All network cabling must be installed according
to applicable codes and regulations.
Camera description
Figure 1: IP fixed lens bullet camera
Adjustable
bracket
Housing
Ethernet RJ45 PoE port
Grounding screw
20
Sunshield
12 VDC power
Reset button
Installation Guide
