1BChapter 2: Installation

Package contents

Check the package and contents for visible damage. If any components are
damaged or missing, do not attempt to use the unit; contact the supplier
immediately. If the unit is returned, it must be shipped back in its original
packaging.
Package contents:
• Camera
• Hex wrench
• Mounting plate (except wedge dome cameras)
• Video cable for testing (except wedge dome cameras)
• Multilingual quick start guide
• CD with user manual in several languages
CAUTION: Use direct plug-in UL listed power supplies marked Class 2/CE
certified or LPS (limited power source) of the required output rating as listed on
the unit.

Cable requirements

For proper operation, adhere to the following cable and power requirements for
the cameras. Category 5 cabling or better is recommended. All network cabling
must be installed according to applicable codes and regulations.
Table 1 below lists the requirements for the cables that connect to the camera.
Table 1: Recommended cable requirements
Cable type
Data
Video
Power
4
Requirements
For RS-485: 22 gauge (0.64 mm) shielded, two-conductor, twisted-pair
(STP) cable.
75 ohm RS-59 coaxial cable with BNC ends
12 VDC cable
