- Page 1 TruVision HD-TVI Bullet Camera Installation Guide P/N 1073685-EN • REV B • ISS 26NOV19...
-
Page 3: Table Of Contents
Contents Product overview 2 Package contents 3 Camera description 10 Installation 14 Installation environment 14 Mounting the HD-TVI fixed lens bullet camera (TVB-6102, TVB-6104) 16 Mounting the HD-TVI VF motorized lens bullet camera (TVB-6101, TVB-6103, TVB-6105, TVB-6106) 19 Mounting the HD-TVI fixed lens low light bullet camera (TVB-6107) 24 Specifications 27 Contact information and manuals /... -
Page 4: Product Overview
Product overview This is the installation guide for TruVision HD-TVI bullet camera models: HD-TVI fixed lens bullet camera: TVB-6102 (2MPx Bullet, 3.6 mm lens) TVB-6104 (5MPx Bullet, 3.6 mm lens) HD-TVI VF motorized lens bullet camera: TVB-6101 (720P Bullet, 2.7 to 13.5 mm lens) ... -
Page 5: Package Contents
Go to “Contact information and manuals” on page 29 for information on where to download the configuration manual for these cameras. Package contents Check the package and contents for visible damage. If any components are damaged or missing, do not attempt to use the unit; contact the supplier immediately. - Page 6 HD-TVI fixed lens bullet camera (TVB- 6102, TVB-6104) Camera with 3 screws and 3 power and video anchors output cable harness (cables not shown) Mounting Installation guide template Installation Guide...
- Page 7 • 12 VDC • Torx wrench connector: Two terminal connector with positive and negative indicators • Equipment disposal sheet Installation Guide...
- Page 8 HD-TVI VF motorized lens bullet camera (TVB-6101, TVB-6103, TVB- 6105, TVB-6106) Camera with 4 screws and 4 power and video anchors for the output cable camera harness (cables not shown) • 3 screws and 3 4 screws to anchors.
- Page 9 • Torx wrench • Back box (included with camera) • 4 screws. Used • Mounting with the back box template Installation guide • Equipment disposal sheet Installation Guide...
- Page 10 HD-TVI fixed lens low light bullet camera (TVB-6107) Camera with 3 screws and 3 power and video anchors output cable harness (cables not shown) Mounting Installation guide template Installation Guide...
- Page 11 • 12 VDC • Torx wrench connector: Two terminal connector with positive and negative indicators • Equipment disposal sheet Installation Guide...
-
Page 12: Camera Description
Camera description Figure 1: HD-TVI fixed lens bullet camera (TVB- 6102, TVB-6104) TVI/960H analog Mounting base switch button Camera body 12 VDC power Lens TVI output Installation Guide... - Page 13 Figure 2: HD-TVI VF motorized lens bullet camera (TVB-6101) TVI output Mounting base 12 VDC/24 VAC Sunshield power Lens TVI/960H analog Camera body (connect wires to switch to 960H analog) Installation Guide...
- Page 14 HD-TVI VF motorized lens bullet camera (TVB- 6103, TVB-6105, TVB-6106) TVI output Mounting base 12 VDC/24 VAC Sunshield power Lens TVI/960H analog Camera body switch button Installation Guide...
- Page 15 Figure 7: HD-TVI fixed lens low light bullet camera (TVB-6107) Lens TVI output Camera body 12 VDC power Mounting base TVI/960H analog switch button Installation Guide...
-
Page 16: Installation
Installation This section provides information on how to install the cameras. Installation environment When installing your product, consider these factors: • Electrical: Install electrical wiring carefully. It should be done by qualified service personnel. Always use a proper 12 VDC UL listed Class 2 CE certified power supply or a proper 24 VAC power supply, depending on the camera. - Page 17 to + 60°C (-40 to 140°F). Humidity is below 90%. • Moisture: Do not expose the camera to rain or moisture, or try to operate it in wet areas. Turn the power off immediately if the camera is wet and ask a qualified service person for servicing.
-
Page 18: Mounting The Hd-Tvi Fixed Lens Bullet Camera (Tvb-6102, Tvb-6104)
Mounting the HD-TVI fixed lens bullet camera (TVB-6102, TVB- 6104) Surface mount 1. Place the provided template level against the mounting surface and mark the position of the mounting holes. te m p l a te 2. Following all local safety regulations, drill and prepare the mounting and cable access (if required) holes. - Page 19 5. Connect the corresponding cables. Power up the camera to check if the monitor displays the desired view. 6. Adjust the camera to get the best viewing angle. See the figure below. P: 360° R: 360° T: 180° ...
- Page 20 a) Loosen the P disk (1) to adjust the pan direction [0-360°]. Tighten after completing the adjustment. b) Loosen the T screw (2) to adjust the tilt direction [0-180°]. Tighten the screw after completing the adjustment. c) Loosen the R screw (3) and rotate the camera [0-360°] to adjust the lens to the desired surveillance angle.
-
Page 21: Mounting The Hd-Tvi Vf Motorized Lens Bullet Camera (Tvb-6101, Tvb-6103, Tvb-6105, Tvb-6106)
Mounting the HD-TVI VF motorized lens bullet camera (TVB-6101, TVB-6103, TVB-6105, TVB-6106) Surface mount 1. Place the provided template level against the mounting surface and mark the position of the mounting holes. 2. Following all local safety regulations, drill and prepare the mounting and cable access (if required) holes. - Page 22 4. Secure the camera to the mounting surface with the provided hardware. 5. Connect the corresponding cables. Power up the camera to check if the monitor displays the desired view. 6. Adjust the camera to get the best viewing angle. See the figure below. Installation Guide...
- Page 23 a) Loosen the P screw (1) crew to adjust the pan direction [0-360°]. Tighten the screw after completing the adjustment. b) Loosen the T screw (2) to adjust the tilt direction [0-180°]. Tighten the screw after completing the adjustment. c) Loosen the R screw (3) and rotate the camera [0-360°] to adjust the lens to the desired surveillance angle.
- Page 24 camera to the back box cover using the screws provided. See figure below. 3. Place the provided template level against the mounting surface and mark the position of the mounting holes. 4. Following all local safety regulations, drill and prepare the mounting holes. 5.
- Page 25 6. Connect the corresponding cables and install the back box cover with camera to the back box. Power up the camera to check if the monitor displays the desired view. 7. Refer to step 6 of “Surface mount” on page 19 to adjust the camera to the desired viewing angle.
-
Page 26: Mounting The Hd-Tvi Fixed Lens Low Light Bullet Camera (Tvb-6107)
Mounting the HD-TVI fixed lens low light bullet camera (TVB- 6107) Surface mount 1. Place the provided template level against the mounting surface and mark the position of the mounting holes. 2. Following all local safety regulations, drill and prepare the mounting and cable access (if required) holes. - Page 27 5. Connect the corresponding cables. 6. Adjust the camera to get the best viewing angle. See the figure below. P: 360° R: 360° T: 180° P (pan) adjustment. Pan position range: 0-360° T (tilt) adjustment. Tilt position range: 0-180° R (rotation) adjustment.
- Page 28 Loosen the P disk to adjust the pan direction [0-360°]. Tighten the screw after completing the adjustment. b) Loosen the T screw to adjust the tilt direction [0-180°]. Tighten the screw after completing the adjustment. c) Loosen the R screw and rotate the camera [0-360°] to adjust the lens to the desired surveillance angle.
-
Page 29: Specifications
Specifications Power supply: 12 VDC / 24 VAC Current power consumption: TVB-6101: 12 VDC: Max. 720 mA / 24 VAC: Max. 447 mA, Max. 8.7 W TVB-6102: 12VDC: Max.282 mA, Max. 3.4 W TVB-6103: 12 VDC: Max. 750 mA / 24 VAC: Max. - Page 30 TVB-6104/TVT-6101: 12 VDC: Max. 245 mA, Max. 3 W Weight (net): TVB-6101/TVB-6103/TVB-6105/ TVB- 6106: 930 g / 2.05 lb. TVB-6102/TVB-6104: 340 g / 0.75 lb. TVB-6107: 436 g / 0.96 lb. Dimensions: TVB-6101/TVB-6103/TVB-6105/ TVB- 6106: 255.2 × 84 mm / 10 × 3.3 in. TVB-6102/TVB-6104: 158.6 ×58 mm / 6.417 ×2.28 in.
-
Page 31: Contact Information And Manuals / Firmware
Manuals are available in several languages. Australia/ www.utcfs.com.au Zealand: Legal and regulatory information Copyright: © 2019 United Technologies Corporation. All rights reserved. Interlogix is part of UTC Climate, Controls & Security, a unit of United Technologies Corporation. Installation Guide... - Page 32 Trade names used in this document may be trademarks or registered trademarks of the manufacturers or vendors of the respective products. Manufacturer: Interlogix 2955 Red Hill Avenue, Costa Mesa, CA 92626-5923, USA Authorized EU manufacturing representative: UTC Fire & Security B.V.
- Page 33 (2) This Device must accept any interference received, including interference that may cause undesired operation. ACMA compliance: Notice! This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.
- Page 34 2013/56/EU & 2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted municipal waste in the European Union. See the product documentation for specific battery information. The battery is marked with this symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg).
- Page 35 For more information on warranty disclaimers and product safety information, please check www.firesecurityproducts.com/policy/product-warning/ or scan the following code: Installation Guide...
