Page 1: Installation Guide
TruVision IR Bullet Camera TVB-2201/TVB-4201 and TVB-2202/TVB-4202 Installation Guide P/N 1072924 • REV A • ISS 10FEB15... -
Page 2: Table Of Contents
Product overview 2 Camera description 4 Installation 4 Specifications 6 Regulatory Information 7 Product overview This is the TruVision IR Bullet Camera Installation Guide for models TVB-2201 / TVB-2202 / TVB-4201 / TVB-4202. This guide describes a standard installation. Installation Guide... -
Page 3: Package Contents
Package contents: Camera with power 3 M4 screws (3 x and video output 25 mm) and 4 dry cables wall anchors (Ø7.5 x 24.5 mm) for wall or ceiling installation Template Installation Guide • WEEE and Battery Disposal Installation Guide... -
Page 4: Camera Description
Camera description 1. Video cable 4. Sun shield 2. Power cable 5. Lens 3. Mounting base 6. IR LED Installation To install the camera: Using the template, place it level against the mounting surface and mark the position of the mounting holes. - Page 5 Drill Template Following all local codes, drill and prepare the mounting holes. Securely fasten the mount to the mounting surface with the supplied screws. Connect a 75-ohm coaxial video cable to the video cable and a 12 VDC power supply to the power cable.
-
Page 6: Specifications
360° 90° 360° Retighten the bracket screws. Specifications Power supply 12 VDC Current Max. 330 mA Power 1.8 W max.(Max. 4 W with consumption IR cut filter on) Weight 0.79 lb. (360 g) Dimensions 2.76 x 5.89 in. (Ø × L) (70 x 149.5 mm) Installation Guide... -
Page 7: Regulatory Information
Regulatory Information Copyright: © 2015 United Technologies Corporation. Interlogix is part of UTC Building & Industrial Systems, a unit of United Technologies Corporation. All rights reserved. Trademarks and patents: Trade names used in this document may be trademarks or registered trademarks of the manufacturers or vendors of the respective products. -
Page 8: Contact Information
For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points. For more information see: www.recyclethis.info. Contact information: For contact information, see www.interlogix.com or www.utcfssecurityproducts.eu. Installation Guide...
