- Page 1 TruVision High Definition TVI Camera Configuration Manual TVB-2402/TVB-4402 TVD-2402/TVD-4402 P/N 1072941-EN • REV A • ISS 10MAR15...
- Page 2 Copyright © 2015 United Technologies Corporation, Interlogix is part of UTC Building & Industrial Systems, a unit of United Technologies Corporation. All rights reserved. Trademarks and Trade names used in this document may be trademarks or patents registered trademarks of the manufacturers or vendors of the respective products.
-
Page 3: Table Of Contents
Content Introduction 2 Programming 2 Menu 4 Automatic Exposure (AE) 4 White Balance (WB) 5 Day & Night 5 Video Setting 6 Function 6 Reset 8 TruVision High Definition TVI Camera Configuration Manual... -
Page 4: Introduction
You can also configure the camera settings via a TVI DVR, select PTZ protocol as TruVision Coax and click the menu button to call the menu. Note: Interlogix offers two different versions of the OSD Controller: the TVS-C100 controller and the TVS-C200 controller. Please choose the corresponding controller by referring to product datasheets. - Page 5 Figure 1: TVS-C200 coax controller 1. Indicator light 2. Arrow keys 3. OK button The Setup menu provides access to the camera configuration options. Before using the controller, please check to ensure that the controller has power. Two AAA batteries are required for the controller to work properly. 1.
-
Page 6: Menu
Menu Automatic Exposure (AE) Automatic exposure (AE) allows you to automatically set the proper exposure according to the existing light conditions. Move the cursor to MAIN MENU > AE, to adjust the image brightness using the BRIGHTNESS, AE MODE, AGC, and SENS-UP options. BRIGHTNESS: Brightness refers to the brightness of the image. -
Page 7: White Balance (Wb)
both very bright and very dark areas simultaneously in the field of view, D- WDR balances the brightness level of the whole image and provide clear images with details. AGC: This is a form of amplification where the camera will automatically boost the image received in much lower light conditions than standard in order to optimize the clarity of image in poor light scene. -
Page 8: Video Setting
Video Setting Move the cursor to the MAIN MENU >VIDEO SETTING. CONTRAST: This feature enhances the difference in color and light between parts of an image. Set the CONTRAST value from 1 to 10. SHARPNESS: Sharpness determines the amount of detail an imaging system can reproduce. - Page 9 DETECTION: In the user-defined detection surveillance area, the moving object can be detected and the alarm will be triggered. Set the motion sensitivity as WEAK, LOW, MIDDLE or HIGH. Select an AREA to enter the motion detection AREA menu. MASKING: Masking allows you to cover certain areas that you do not want to be viewed or recorded.
-
Page 10: Reset
AREA: There can be eight masking areas set for motion detection. Set the status as OFF/ON. Move the joystick up/down and right/left to set the horizon/vertical size and position. Reset Move the cursor to the MAIN MENU >RESET. This resets all the settings to default.
