AX93276 Connectors, Switches and LED
Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, please make sure all connectors are properly and firmly connected.
Here is a summary table which shows all connectors, buttons and LED on the hardware.
Connector
CN1
CN2
CN3
CN4
CN5
CN6
CN7A~CN7B
CN8
CN9
D1
A.12.1
Power Connector (CN1)
This is a 2-pin (pitch=2.5mm) connector, which outputs +5V at 1A for fan to cool down
CPU and system temperature.
Pin
1
2
I/O Boards (Optional)
Description
Power Connector
High Speed Board to Board Connector 1
High Speed Board to Board Connector 2
LAN and USB 3.0 Connector
System Power Switch
USB 3.0 Stack Connector
COM1 and COM2 D-Sub Connectors
HDMI Connector
System Reset Switch
Power and HDD LED Indicator
Signal
+5V
GND
PICO300 Pico-ITX Board
69
