USB 2.0 Wafer Connector (CN5)

This is a 4-pin (pitch=1.25mm) wafer connector which is compliant with Molex
530470410 for USB 2.0 interface.
Pin
1
2
3
4
2.5.4

Fan Power Connector (CN6)

The CN6 is a 2-pin (pitch=1.5mm) wafer connector which is compliant with JST
B2B-ZH-K-S for fan power interface.
Pin
1
2
2.5.5

SMBus Connector (CN7)

This connector is for SMBus (System Management Bus) interface.
Pin
1
2
3
16
Signal
USB_PWR
D+
D-
GND
Signal
+5V
GND
Signal
SMBus clock
SMBus data
GND
