  • Page 1 PICO511 ® Generation Intel Core i7/ i5/ i3 ® and Celeron ULT Processors Pico-ITX Board User’s Manual...
  • Page 2 Axiomtek does not make any commitment to update the information in this manual. Axiomtek reserves the right to change or revise this document and/or product at any time without notice. No part of this document may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of Axiomtek Co., Ltd.

  • Page 3: Esd Precautions

    It discharges static electricity from your body.  Wear a wrist-grounding strap, available from most electronic component stores, when handling boards and components. Trademarks Acknowledgments Axiomtek is a trademark of Axiomtek Co., Ltd. ® ® Intel and Celeron are trademarks of Intel Corporation.

  • Page 4: Table Of Contents

    Table of Contents Disclaimers ..................... ii ESD Precautions ................... iii Chapter 1 Introduction ..........1 Features ....................2 Specifications ..................2 Utilities ....................3 Chapter 2 Board and Pin Assignments ....5 Board Dimensions and Fixing Holes ..........5 Board Layout ..................7 Assembly Drawing ................
  • Page 5 I/O Port Address Map ................ 26 Interrupt Controller (IRQ) Map ............28 Memory Map ..................37 Chapter 4 AMI BIOS Setup Utility ......39 Starting ....................39 Navigation Keys ................39 Main Menu ..................41 Advanced Menu ................. 42 Chipset Menu ..................54 Security Menu ..................
  • Page 6 This page is intentionally left blank.

  • Page 7: Chapter 1 Introduction

    PICO511 Pico-ITX Board Chapter 1 Introduction ® ® The PICO511 is a Pico-ITX board with 7 Generation Intel Core i7/ i5/ i3 and Celeron processor that delivers outstanding system performance through high-bandwidth interfaces, multiple I/O functions for interactive applications and various embedded computing solutions.

  • Page 8: Features

    PICO511 Pico-ITX Board Features ® ®  Generation Intel Core i7/ i5/ i3 and Celeron ULT processor  1 DDR4 SO-DIMM supports up to 16GB memory capacity  1 USB 2.0 port and 1 Gigabit Ethernet port  1 PCI-Express Mini Card Specifications ...

  • Page 9: Utilities

    PICO511 Pico-ITX Board  Power Input  DC jack power connector, co-layout with 1x2-pin right angle connector.  +12V DC-in only.  AT auto power on function supported.  Power Management  ACPI (Advanced Configuration and Power Interface).  Form Factor ...
  • Page 10 PICO511 Pico-ITX Board This page is intentionally left blank. Introduction...

  • Page 11: Board And Pin Assignments

    PICO511 Pico-ITX Board Chapter 2 Board and Pin Assignments Board Dimensions and Fixing Holes Top View Board and Pin Assignments...
  • Page 12 PICO511 Pico-ITX Board Bottom View Side View Board and Pin Assignments...

  • Page 13: Board Layout

    PICO511 Pico-ITX Board Board Layout Top View Board and Pin Assignments...
  • Page 14 PICO511 Pico-ITX Board Bottom View Board and Pin Assignments...

  • Page 15: Assembly Drawing

    PICO511 Pico-ITX Board Assembly Drawing For thermal dissipation, a thermal solution enables the PICO511’s components to dissipate heat efficiently. All heat generating components are thermally conducted to the heatsink in order to avoid hot spots. Images below illustrate how to install the thermal solution on PICO511.
  • Page 16 Use the following four screws to secure heatsink on heatspreader. The PICO511 has four assembly holes for installation. Align and firmly secure thermal solution and AX93A07 I/O board to PICO511. Be careful not to over-tighten the screws. Thermal Solution PICO511: ①...

  • Page 17: Wiring Connection

    PICO511 Pico-ITX Board 2.3.1 Wiring Connection Before proceeding with connecting PICO511 and AX93A07 I/O board, please make sure the system power is completely off. Connect the two boards with the following information: Function PICO511 AX93A07 SMBus (for VGA) CN10 Power...

  • Page 18: Jumper Settings

    And remove jumper clip from 2 jumper pins to open. Below illustration shows how to set up jumper. Properly configure jumper settings on the PICO511 to meet your application purpose. Below you can find a summary table of jumpers and onboard default settings.

  • Page 19: Restore Bios Optimal Defaults (Jp2)

    PICO511 Pico-ITX Board 2.4.1 Restore BIOS Optimal Defaults (JP2) Put jumper clip to pin 2-3 for a few seconds then move it back to pin 1-2. Doing this procedure can restore BIOS optimal defaults. Function Setting Normal (Default) 1-2 close...

  • Page 20: Connectors

    PICO511 Pico-ITX Board Connectors Signals go to other parts of the system through connectors. Loose or improper connection might cause problems, please make sure all connectors are properly and firmly connected. Here is a summary table which shows all connectors on the hardware.

  • Page 21: Board To Board Connectors (Cn2 And Cn3)

    PICO511 Pico-ITX Board 2.5.1 Board to Board Connectors (CN2 and CN3) CN2 is a 2x30-pin board to board connector. The pin assignments are given as follows. Signal Signal HDA_SYNC HDA_BCLK HDA_SDI HDA_RST HDA_SDO HDA_VCCIO COM3_EN COM4_EN COM3_TERM COM4_TERM Samtec COM3_GPIO0 COM4_GPIO0 LSHM-130-04.0-F-DV-A-N-K-TR...
  • Page 22 SMB_CLK +3.3V_SBY +3.3V_SBY  It is suggested to insert I/O board (AX93A00, AX93A01, AX93A02 or AX93A09 ) into CN2 and CN3 on PICO511. Note  If the VGA or HDMI display on I/O board (AX93A00 or AX93A01) is set ®...

  • Page 23: Sata Connector (Cn4)

    PICO511 Pico-ITX Board 2.5.2 SATA Connector (CN4) This Serial Advanced Technology Attachment (Serial ATA or SATA) connector is for high speed SATA interface. It is a computer bus interface for connecting to devices such as hard disk drive. Signal 2.5.3 USB 2.0 Wafer Connector (CN5)

  • Page 24: Cmos Battery Connector (Cn8)

    PICO511 Pico-ITX Board 2.5.6 CMOS Battery Connector (CN8) This connector is for CMOS battery interface. Signal +3.3V 2.5.7 Front Panel Connector (CN9) This is a 2x5-pin (pitch=2.0mm) wafer connector. Signal PS_ON Power LED- Power LED+ PS_IN HW Reset HDD LED-...

  • Page 25: Fan Power Connector (Cn11)

    PICO511 Pico-ITX Board 2.5.9 Fan Power Connector (CN11) The CN11 is a 2-pin (pitch=1.5mm) wafer connector for fan power interface. Signal 2.5.10 LVDS Connector (CN12) This board has a 2x20-pin connector for LVDS LCD interface. It is strongly recommended to use the matching JST SHDR-40VS-B connector for LVDS interface.
  • Page 26 PICO511 Pico-ITX Board 24-bit single channel 18-bit dual channel Pin Signal Pin Signal Pin Signal Pin Signal VCCM VCCM VCCM VCCM VCCM VCCM VCCM VCCM VCCM VCCM VCCM VCCM 10 GND 10 GND 11 N.C 12 N.C 11 N.C 12 Channel B D0- 13 N.C...

  • Page 27: Inverter Connector (Cn13)

    PICO511 Pico-ITX Board 2.5.11 Inverter Connector (CN13) This is DF13-8S-1.25C 8-pin connector for inverter. We strongly recommend you to use the matching DF13-8S-1.25C connector to avoid malfunction. Signal VBL1 (+12V level) VBL1 (+12V level) VBL2 (+5V level) VBL_ENABLE VBL Brightness Control 2.5.12...

  • Page 28: Full-Size Pci-Express Mini Card Or Msata Connector (Scn1)

    PICO511 Pico-ITX Board 2.5.14 Full-size PCI-Express Mini Card or mSATA Connector (SCN1) This is a full-size PCI-Express Mini Card connector on the bottom side complying with PCI-Express Mini Card Spec. V1.2. It supports either PCI-Express, USB 2.0 or SATA (mSATA). To enable or disable mSATA support, please refer to BIOS setting in section 4.4.

  • Page 29: Half-Size Pci-Express Mini Card Connector (Scn3)

    PICO511 Pico-ITX Board 2.5.15 Half-size PCI-Express Mini Card Connector (SCN3) This is a half-size PCI-Express Mini Card connector on the bottom side complying with PCI-Express Mini Card Spec. V1.2. It supports either PCI-Express or USB 2.0. Signal Signal WAKE# +3.3VSB...
  • Page 30 PICO511 Pico-ITX Board This page is intentionally left blank. Board and Pin Assignments...

  • Page 31: Chapter 3 Hardware Description

    CPU from damages. BIOS The PICO511 uses AMI Plug and Play BIOS with a single 128Mbit SPI Flash. System Memory The PICO511 supports one 260-pin DDR4 SO-DIMM socket for maximum memory capacity up to 16GB DDR4 SDRAMs.

  • Page 32: I/O Port Address Map

    PICO511 Pico-ITX Board I/O Port Address Map Hardware Description...
  • Page 33 PICO511 Pico-ITX Board Hardware Description...

  • Page 34: Interrupt Controller (Irq) Map

    PICO511 Pico-ITX Board Interrupt Controller (IRQ) Map The interrupt controller (IRQ) mapping list is shown as follows: Hardware Description...
  • Page 35 PICO511 Pico-ITX Board Hardware Description...
  • Page 36 PICO511 Pico-ITX Board Hardware Description...
  • Page 37 PICO511 Pico-ITX Board Hardware Description...
  • Page 38 PICO511 Pico-ITX Board Hardware Description...
  • Page 39 PICO511 Pico-ITX Board Hardware Description...
  • Page 40 PICO511 Pico-ITX Board Hardware Description...
  • Page 41 PICO511 Pico-ITX Board Hardware Description...
  • Page 42 PICO511 Pico-ITX Board Hardware Description...

  • Page 43: Memory Map

    PICO511 Pico-ITX Board Memory Map The memory mapping list is shown as follows: Hardware Description...
  • Page 44 PICO511 Pico-ITX Board This page is intentionally left blank. Hardware Description...

  • Page 45: Ami Bios Setup Utility

    PICO511 Pico-ITX Board Chapter 4 AMI BIOS Setup Utility The AMI UEFI BIOS provides users with a built-in setup program to modify basic system configuration. All configured parameters are stored in a flash chip to save the setup information whenever the power is turned off. This chapter provides users with detailed description about how to set up basic system configuration through the AMI BIOS setup utility.
  • Page 46 PICO511 Pico-ITX Board Hot Keys Description  Left/Right The Left and Right <Arrow> keys allow you to select a setup screen. The Up and Down <Arrow> keys allow you to select a setup screen or  Up/Down sub-screen. The Plus and Minus <Arrow> keys allow you to change the field value of a +...

  • Page 47: Main Menu

    PICO511 Pico-ITX Board Main Menu When you first enter the setup utility, you will enter the Main setup screen. You can always return to the Main setup screen by selecting the Main tab. System Time/Date can be set up as described below.

  • Page 48: Advanced Menu

    PICO511 Pico-ITX Board Advanced Menu The Advanced menu also allows users to set configuration of the CPU and other system devices. You can select any of the items in the left frame of the screen to go to the sub menus: ►...
  • Page 49 PICO511 Pico-ITX Board  Hardware Monitor This screen monitors hardware health status. This screen displays the temperature of system and CPU, system voltages (VBAT, +3.3V, +3.3V_SBY and +5V). AMI BIOS Setup Utility...
  • Page 50 PICO511 Pico-ITX Board  ACPI Settings ACPI Sleep State The setting is S3 (Suspend to RAM); this option selects ACPI sleep state the system will enter when suspend button is pressed. AMI BIOS Setup Utility...
  • Page 51 PICO511 Pico-ITX Board  CPU Configuration This screen shows the CPU Configuration and you can change the value of the selected option. Intel (VMX) Virtualization Technology Enable or disable Intel Virtualization Technology. When enabled, a VMM (Virtual Machine Mode) can utilize the additional hardware capabilities. It allows a platform to run multiple operating systems and applications independently, hence enabling a computer system to work as several virtual systems.
  • Page 52 PICO511 Pico-ITX Board  SATA Configuration In the SATA Configuration menu, you can see the current installed hardware in the SATA ports. During system boot up, the BIOS automatically detects the presence of SATA devices. SATA Mode Selection The SATA mode is set to AHCI.
  • Page 53 PICO511 Pico-ITX Board  PCH-FW Configuration This screen displays ME Firmware information.  AMT Configuration Use this screen to configure AMT parameters. AMT BIOS Features Enable or disable AMT (Active Management Technology) BIOS features. The default is Enabled. After enabling, please refer to Appendix C for iAMT settings.
  • Page 54 PICO511 Pico-ITX Board  USB Configuration USB Devices Display all detected USB devices.  Utility Configuration BIOS Flash Utility BIOS flash utility configuration. For more detailed information, please refer to Appendix D. AMI BIOS Setup Utility...
  • Page 55 This option appears only if an I/O board is installed CN2 and CN3 (See Section 2.5.1). BIOS will auto-detect all supported functions and you can use it to change settings on the I/O board. The PICO511 supports the following I/O boards: AX93A00, AX93A01, AX93A02 and AX93A09.
  • Page 56 PICO511 Pico-ITX Board  Module Device Configuration This screen is available only if an I/O board with serial ports is connected. For items marked with “”, please press <Enter> for more options.  AxiomType3 Super IO Configuration Serial Port 1~2 Configuration Set parameters related to serial port 1~2 on I/O board.
  • Page 57 PICO511 Pico-ITX Board  Serial Port 1 Configuration Serial Port Enable or disable serial port 1 on I/O board. The optimal setting for base I/O address is 3F8h and for interrupt request address is IRQ4. COM Port Type Use this item to set RS-232/422/485 communication mode.
  • Page 58 PICO511 Pico-ITX Board Terminal Mode Enable or disable terminal mode.  Serial Port 2 Configuration Serial Port Enable or disable serial port 2 on I/O board. The optimal setting for base I/O address is 2F8h and for interrupt request address is IRQ3.
  • Page 59 PICO511 Pico-ITX Board COM Port Type Use this item to set RS-232/422/485 communication mode. Terminal Mode Enable or disable terminal mode. AMI BIOS Setup Utility...

  • Page 60: Chipset Menu

    PICO511 Pico-ITX Board Chipset Menu The Chipset menu allows users to change the advanced chipset settings. You can select any of the items in the left frame of the screen to go to the sub menus: ► PCH-IO Configuration ►...
  • Page 61 PICO511 Pico-ITX Board  HD Audio Configuration For items marked with “”, please press <Enter> for more options. HD Audio Configuration Use this item to set HD audio configuration. HD Audio Enable or disable HD audio device. AMI BIOS Setup Utility...
  • Page 62 PICO511 Pico-ITX Board  System Agent (SA) Configuration Graphics Configuration Use this item to open graphics configuration sub screen. Memory Configuration Use this item to refer to information related to system memory. AMI BIOS Setup Utility...
  • Page 63 PICO511 Pico-ITX Board For PICO511 with VGA (AX93A00): For PICO511 with HDMI (AX93A01): Primary IGFX Boot Display Select the video device which will be activated during POST (Power-On Self Test). AMI BIOS Setup Utility...
  • Page 64 PICO511 Pico-ITX Board The images below show Primary IGFX Boot Display option list when AX93A07 I/O board is installed. For PICO511+AX93A07 with VGA (AX93A00): For PICO511+AX93A07 with HDMI (AX93A01): For PICO511+AX93A07: AMI BIOS Setup Utility...
  • Page 65 PICO511 Pico-ITX Board LVDS Panel Type Select LVDS panel resolution.  Memory Information This screen shows the system memory information. AMI BIOS Setup Utility...

  • Page 66: Security Menu

    PICO511 Pico-ITX Board Security Menu The Security menu allows users to change the security settings for the system.  Setup Administrator Password Use this item to set setup administrator password.  User Password Use this item to set user password.

  • Page 67: Boot Menu

    PICO511 Pico-ITX Board Boot Menu The Boot menu allows users to change boot options of the system.  Bootup NumLock State Use this item to select the power-on state for the keyboard NumLock.  Quiet Boot Select to display either POST output messages or a splash screen during boot-up.
  • Page 68 PICO511 Pico-ITX Board  Launch PXE OpROM Use this item to enable or disable the boot ROM function of the onboard LAN chip when the system boots up. Boot Option Priorities [Boot Option #1, …]  These are settings for boot priority. Specify the boot device priority sequence from the available devices.

  • Page 69: Save & Exit Menu

    PICO511 Pico-ITX Board Save & Exit Menu The Save & Exit menu allows users to load your system configuration with optimal or fail-safe default values.  Save Changes and Exit When you have completed the system configuration changes, select this option to leave Setup and return to Main Menu.
  • Page 70 PICO511 Pico-ITX Board  Discard Changes Select this option to discard changes done so far and load previous values. Select Discard Changes from the Save & Exit menu and press <Enter>. Select Yes to discard changes.  Restore Defaults It automatically sets all Setup options to a complete set of default settings when you select this option.

  • Page 71: Appendix A I/O Board

    PICO511 Pico-ITX Board Appendix A I/O Board The AX93A07 is an I/O expansion board which is suggested to attach carefully to PICO511. Its specifications and detailed information are given in this appendix. AX93A07 Specifications  Size  100mm x 26mm ...

  • Page 72: Ax93A07 Board Layout

    PICO511 Pico-ITX Board Bottom View Side View AX93A07 Board Layout Top View Side View I/O Board...

  • Page 73: Ax93A07 Connectors

    100 LAN LED MDI3- MDI3+ MDI1- MDI2- MDI2+ MDI1+ MDI0- MDI0+ LAN_VDD33 LAN_LINK_ACT A.4.2 DC Power Output Connector (CN2) This is a 4-pin wafer connector for DC +12V. Gently connect this CN2 to PICO511’s CN14. Signal +12V +12V I/O Board...

  • Page 74: Lvds Input Connector (Cn3)

    JST SHDR-40VS-B connector. The LVDS input signals go through this connector and converted by CH7036 IC to VGA signals on CN8. Note that pin 1~6 VCCM must be set to +5V. Gently connect this CN3 to PICO511’s CN12.

  • Page 75: Ethernet Port (Cn6)

    PICO511 Pico-ITX Board A.4.6 RJ-45 Ethernet Port (CN6) The board has one RJ-45 Ethernet connector. Connection can be established by plugging one end of the Ethernet cable into this RJ-45 and the other end (phone jack) to a 1000/100/10 Base-T hub.
  • Page 76 PICO511 Pico-ITX Board This page is intentionally left blank. I/O Board...

  • Page 77: Appendix B Watchdog Timer

    PICO511 Pico-ITX Board Appendix B Watchdog Timer B.1 About Watchdog Timer After the system stops working for a while, it can be auto-reset by the watchdog timer. The integrated watchdog timer can be set up in the system reset mode by program.
  • Page 78 PICO511 Pico-ITX Board This page is intentionally left blank. Watchdog Timer...

  • Page 79: Appendix C Iamt Settings

    PICO511 Pico-ITX Board Appendix C iAMT Settings ® ® The Intel Active Management Technology (Intel iAMT) has decreased a major barrier to IT efficiency that uses built-in platform capabilities and popular third-party management and security applications to allow IT a better discovering, healing, and protection their networked computing assets.
  • Page 80 PICO511 Pico-ITX Board You will be asked to change the password before setting ME. You must confirm your new password while revising. The new password must contain: (example: !!11qqQQ) (default value).  Eight characters  One upper case  One lower case ...

  • Page 81: Iamt Configuration

    PICO511 Pico-ITX Board iAMT Configuration ® From Main Menu, select Intel Standard Manageability Configuration and press <Enter>. Set Manageability Feature Selection to Enabled. iAMT Settings...
  • Page 82 PICO511 Pico-ITX Board  SOL/Storage Redirection/KVM This screen enabling disabling Serial-over-LAN (SOL)/Storage Redirection/Keyboard Video Mouse (KVM) functionality.  User Consent User Opt-in Configure this item when user consent should be required. Opt-in Configurable from Remote IT Enable or disable remote change capability of user consent feature.
  • Page 83 PICO511 Pico-ITX Board  Network Setup ® 1. From Intel AMT Configuration Menu, select Network Setup. 2. Select ME Network Name Settings to set computer host and domain name. iAMT Settings...
  • Page 84 PICO511 Pico-ITX Board 3. Select TCP/IP to get into Network interface. Get into DHCP Mode and set it to Disabled. iAMT Settings...
  • Page 85 PICO511 Pico-ITX Board 4. If DHCP Mode is disabled, set the following settings:  IP address  Subnet mask 5. Go back to Intel® iAMT Configuration, then select Activate Network Access and press <Enter>. 6. Exit from MEBx after completing the iAMT settings.
  • Page 86 PICO511 Pico-ITX Board  Remote Setup and Configuration 1. Select TLS PKI to get into remote configuration screen. Then select Start Configuration to activate it. iAMT Settings...
  • Page 87 PICO511 Pico-ITX Board 2. Select Manage Hashes to add, delete and activate hash. iAMT Settings...
  • Page 88 PICO511 Pico-ITX Board  Power Control AMT ON in Host Sleep States Select the appropriate AMT ON in Host Sleep States setting. Options are ON in S0 and ON in S0, ME Wake in S3, S4-5 (AC only). Idle Timeout This is timeout value for Wake_On_ME in minutes.

  • Page 89: Iamt Web Console

    PICO511 Pico-ITX Board iAMT Web Console From a web browser, please type http://(IP ADDRESS):16992, which connects to iAMT Web. Example: http://10.1.40.214:16992 To log on, you will be required to type in username and password for access to the Web. USER: admin (default value)
  • Page 90 PICO511 Pico-ITX Board Enter the iAMT Web. Click Remote Control, and select commands on the right side. When you have finished using the iAMT Web console, close the Web browser. iAMT Settings...

  • Page 91: Appendix Dbios Flash Utility

    Please read and follow the instructions below carefully. In your USB flash drive, create a new folder and name it “Axiomtek”, see figure below. Copy BIOS ROM file (e.g. PICO511.005) to “Axiomtek” folder.
  • Page 92 Select the USB drive containing BIOS ROM file you want to update using the <> or <> key. Then press <Enter> to get into “Axiomtek” folder. Now you can see the BIOS ROM file on the screen, press <Enter> to select.
  • Page 93 PICO511 Pico-ITX Board Please wait while BIOS completes the entire flash update process: erase data, write new data and verify data. 10. When you see the following figure, press <Enter> to finish the update process. After that the system will shut down and restart immediately.
