2.4 Keyboard Introduction

The functions of keys on the front panel of the IT6100B series power supply are
shown in the following table.
Key tag
0-9
V-set
V-set
I-set
I-set
Recall
Meter
Meter
Enter
Enter
On/Off
Numerical keys/Secondary Shift Functions:
1
Name and function
Use to access secondary functions
Shift
Enable front panel operation when in remote mode
Local
Power switch
Power
Numerical keys for direct entry of values
Set the voltage value, OVP value
OVP
Set the current value and enter into the menu
Menu
Recall(Save) operating data from internal memory
Save
Switch between Setting/Meter display, also used to
DVM
switch to DVM measuring state.
Press to confirm numerical entries,or provide a
Trigger
trigger signal
Set the output state of the power supply,or to lock
Lock
the front-panel keys
Right/left keys to adjust the position of cursor
Up/down key to overturn the menu items or
increase/decrease the setting value.
Quit the operation
Set the range of the mΩ Meter to 0.1W
(0.1W)
Set the range of the mΩ Meter to 1W
(1W)
