USER'S GUIDE
High Resolution and High Speed
Programmable Power Supply
Models IT6163S/IT6164S/IT6165S
© Copyright 2005
All Rights Reserved
Ver1.1 /July, 2005/ IT6100-527
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IT6163S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ITech IT6163S

  • Page 1 USER’S GUIDE High Resolution and High Speed Programmable Power Supply Models IT6163S/IT6164S/IT6165S © Copyright 2005 All Rights Reserved Ver1.1 /July, 2005/ IT6100-527...
  • Page 2: Table Of Contents

    About your safety ..............................3 General information ............................3 Protection from electric shock ........................3 Definition of users ............................3 Certification and Warranty ............................4 Certification ............................... 4 Warranty ................................4 Limitation of Warranty ..........................4 Introduction ................................4 Chapter1 Quick Reference ............................. 5 1.1 The Front Panel ............................
  • Page 3: About Your Safety

    About your safety Pease review the following safety precautions before operating our equipment. General information The following safety precautions should be observed before using this product and any associated instrumentations. Although some instruments and accessories would be used with non-hazardous voltages, there are situations where hazardous conditions may be present.
  • Page 4: Certification And Warranty

    Certification and Warranty Certification We certify that this product met its published specifications at time of shipment from the factory. Warranty This instrument product is warranted against defects in material and workmanship for a period of one year from date of delivery. During the warranty period we will, at its option, either repair or replace products which prove to be defective.
  • Page 5: Chapter1 Quick Reference

    Chapter1 Quick Reference 1.1 The Front Panel VFD and rotary knob Power switch ON/OFF Number Keys Function Keys Up, down and Enter key Ω Input of V/m meter Output terminals 1.2 The Rear Panel     4-Pin Trigger and Remote sensing connectors Power socket Power switch (110V / 220V) 9-Pin COM port interface connector 4-Pin Trigger and Remote sensing connectors...
  • Page 6: Preliminary Checkout

    1.3 Preliminary Checkout The following steps help you verify that the power supply ready for use. 1. Check the list of supplied items Verify that you have received the following items with your power supply. If anything is missing, contact your nearest Sales Office.
  • Page 7: Output Checkout

    Warning: The power supply is shipped from the factory with a power-line cord that has a plug appropriate for your location. Your power supply is equipped with a 3-wire grounding type power cord; the third conductor being the ground. The power supply is grounded only when the power-line cord is plugged into an appropriate receptacle.
  • Page 8: If The Power Supply Does Not Turn On

    3. Verify that the correct power-line fuse is installed. If the fuse was damaged, please see the table below to replace the fuse for your power supply. Fuse Description (220VAC) Model Fuse Description(110VAC) IT6163S IT6164S IT6165S Chapter 2 Specifications 2.1 Specifications...
  • Page 9: Supplemental Characteristics

    2.2 Supplemental Characteristics State Storage Memory Fifteen (50) user-configurable stored stable Recommended Calibration Interval Once a year AC Input Ratings (selectable via switch on the rear panel) Option Opt.01: 220VAC ± 10%, 47 to 63 Hz Option Opt.02: 110 VAC ± 10%, 47 to 63 Hz Cooling Fan cooled Operating Temperature...
  • Page 10: Keyboard Disposal

    3.1Keyboard Disposal V-set I-set Save Recall Enter · · Shift On/Off Multiple Key Function Key Multiple Key Instruction Ω V/mΩ: 5 Digital Voltage Meter / m Meter Ω 0.1W: The range of m Meter is 0.1W Ω 1W: The range of m Meter is 1W Ω...
  • Page 11: Front-Panel Operation Overview

    3.2 Front-panel Operation Overview The following section describes an overview of the front-panel keys before operating your power supply. 1. The power supply is shipped from the factory configured in the front-panel operation mode. At power-on, the power supply is automatically set to operate in the front-panel operation mode. When in this mode, the front panel keys can be used.
  • Page 12: Menu Operation

    Save Enter You can use and 0~50 numeric key,press , and store the parameter of IT6100 series into the register. Enter Recall You can use and 0~50 numeric key, press , and recall the parameter stored before from the register. 3.6 Menu Operation 3.6.1 Menu Description ▲...
  • Page 13 Default > Baudrate 9600 Baudrate 19200 Baudrate 38400 Comm. Parity Command parity setting. None< Default > Even Address Set Setting communication address(range from 0to 254) Address=** Port Mode Select function of port Trigger< Def > RI/DIF DIGITAL I/O Trig Source Setting trigger mode Immediat<Def>...
  • Page 14: Menu Function

    Repeat Save Mode Set Users can choose 4 kinds of memory space to save the list file. 8 X 25 Steps 4 X 50 Steps 2 X 100 Steps 1 X200 Steps Exit Out On Timer Output timer,if you start this function, the power supply will turnoff after the time you set.
  • Page 15 3) Press▲、▼to select On 项,press ENTER to confirm. 4) Press two times to escape menu operation. V-set V-set I-set I-set ENTER 5) Press , select to set voltage value or current value, press confirm. to set the register number (range from 0 to 9) , Save 6)...
  • Page 16: Key Lock

    Trigger RI/DFI DIGITAL I/O Pinmode Trigger in Inhibit Input Digital Input No Use Fault Output Digital Output No Use Trigger Operation (Shift+Trigger) The power supply has 3 kinds of trigger mode. You must choose trigger source before trigger operating. Shift Trigger Trigger Key: If this function is enabled, press , the power supply will start trigger...
  • Page 17 Shift Menu 1) Press into the menu. Enter 2) Press up or down key to select “Config”, press to confirm. Enter 3) Press up or down key to select “Trig Source”, press to confirm. Enter 4) Press up or down key to select “Immediat”, press to confirm.
  • Page 18: Output Operation

    Trigger Trigger When the list operation mode is STEP, the power supply will come to next step only after it receive a trigger signal. Trigger Trigger Trigger Trigger Trigger Trigger Trigger Trigger Digital I/O When the digital port of the power supply mode is DIGITALI/O and power supply is under remote sense, you could send SCPI order (DIGital:INPut[:STATe?] and DIGital:OUTPut[:STATe?])...
  • Page 19: Milliohm Mete

    IN, GND: trigger port 3.9 Milliohm Mete SOURCE METER can measure resistant value accurately and the most resistant value it can measure is 10Ω. In order to protect the resistant, please select the power range of the resistant before you measure it.
  • Page 20: Chapter 4 Remote Operation Mode

    Ω Ω (if VFD displays Range: **,please press ), set voltage Shift Shift Press +V/m +V/m meter, VFD displays**.**V, you can begin test the voltage value, the max voltage value is 40V. Chapter 4 Remote Operation Mode The DB9 interface connector on the rear panel of the power supply can be transferred to RS-232 interface, the following information will tell you how to use the computer to control the output of the power supply.
  • Page 21: It-E135 Gpib Communication Cable

    IT-E135 GPIB Communication Cable The DB9 interface connector on the rear panel of power supply is TTL voltage level, you can use the GPIB communication cable (IT-E135) to connect the DB9 interface connector of the power supply, and then connect the GPIB interface of the IT-E135 and computer with GPIB/IEEE 488 line for the communication.
