ITech IT6121B User Manual page 26

Comm
Port
Trig
RI
DFI
System SYSTEM MENU
Limit_volt
On_Timer
DVM
OutMode
Range RANGE MENU
RECALL LIST
Edit_List
FILE
Recall 1
On
Off(default)
COMMUNICATION
RS232(def)
USBTMC
GPIB
PORT FUNCTION
Trigger
RI/DFI
Digital
TRIGGER SOURCE
Manual
External
Bus
Immediat
RI MODE
Off
Latching
Live
DFI SOURCE
Off
QUES
OPER
ESB
RQS
LIMIT VOLTAGE SET
Limit=30.10V
ON TIMER STATE
On
Off(default)
DVM RANGE
Auto
Low
High
OUTPUT MODE...
Volt-Wave Prio
Curr-Wave Prio
Set Output Range
Low_Range
High_Range
Copyright © ITECH Electronics Co., Ltd.
Lock the rotary knob
Unlock the rotary knob
Communication port select
Select mode of digital port
Trigger source select
Trigger by keys on the front panel
Ext. Trigger signal is applied to the
digital port in the rear panel.
Remote command trigger mode.
Trigger by TRIG:IMM command
Config RI（Remote Inhibit)mode
Disable this function
Config DFI(Discrete Fault Indicater)
mode
Disable this function
Question bit
Operation bit
Event State bit
Require bit
Output timer function state
ON TIMER SET
timer = 60.000(0.01~60000.0S)
Auto range
Low range
High range
Set Output Mode
Volt Wave Prio
Curr Wave Prio
Low range
High range
Basic operation
19
