Table 1-10 RMX 4000 RTM-IP 4000 LEDs (Continued)
LED
Component
Name
ShMG (Shelf ERR
Manager) LEDs
ACT
RDY
HS

RTM LAN

The following LEDs appear on the RTM LAN:
Table 1-11 RMX 4000 RTM LAN LEDs
LED
Function Name
Name
LAN 1 & 2 LEDs LNK
1 Gb
LED Color Description
Red ON - Major error on RTM-IP
4000 card.
Flashes - During system
startup.
Red ON - Packet flow to and from
the MCU chassis.
Flashes - During system
startup.
Green ON - RTM-IP 4000 card has
successfully completed startup.
Flashes - During system
startup.
Blue OFF - Normal.
Flashes - During power down
process.
ON - RTM-IP 4000 card may be
removed.
LED Color Description
Green ON with an active network
connection, flickers with Packet
activity.
Amber ON when 1Gb connection is
online, flickers with Packet
activity.
1-35
