VQ Model A26K COUNTER INVADER Assembly Instructions Manual page 9

12- Aileron servo / Hohenruderservo
Use the fishing line inside each wing to lead the aileron and
throttle servo extension cord all through the wing.
Fishing line
Hole for servo
connector
Aileron pushrod
Gestängeanschluss
Rudergestänge
2
13. Cowling / Motorhaube
3/32x25/64"(2.5x10mm)
................6
5/64x25/64"screw
2x10mm schraube
..................46
L/R
WING - BOTTOM VIEW
To Throttle servo extension cord
X
Aileron servo arm
5/64"
2 mm
CA
3/32x25/64"screw
2.5x10mm schraube
Cut the opening
UNTERSICHT
To Aileron servo extension cord
Aileron servo extension cord
Servoverlangerungskabe
X
5/64x25/64" screw
2x10mmschraube
1
5/64x25/64"screw screw
2x10mm schraube
5/64x25/64"screw screw
2x10mm schraube
1/16"
1.5mm
25/64"(10mm)
Plastic control horn
............................2
5/64x19/32" screw
2x15mm schraube
....................4
5/64x25/64" screw
2x10mm schraube
......................8
Cut away
only the covering
Secure the rear
shield using sticker
1/8 ~ 13/64"
3 ~ 5 mm
Hatch
X
