Radio control model
SPECIFICATIONS
Wingspan
Length
Electric Motor
Glow Engine
Radio
8 Channels / 11 Servos
Minimum 8 channels radio
for airplane with 11 servos
(in case of gas engine using)
If exposed to direct sunlight and/or heat, wrinkels can appear. Storing the
model in a cool place will let the wrinkles disappear. Otherwise, remove
wrinkles in covering film with a hair dryer, starting with
low temperature. You can fix the corners by using a hot iron.
Symbols used throughout this instruction manual, comprise:
Drill holes using the stated
size of drill
1.5mm
(in this case 1.5 mm Ø)
A B
Use epoxy glue
WARNING! This radio controlled model is NOT a toy. If modified or flown carelessly it could go out of controll and
cause serious human injury or property damage. Before flying your airplane, ensure the air field is spacious enough.
Always fly it outdoors in safe areas and seek professional advice if you are unexperienced.
2100mm
1240mm
800 Watt
.46 2-T / .70 4-T
REQUIRED FOR OPERATION (Purchase separately)
10.5x6 for .40 - 2 cycle engine
11x6 for .46
- 2 cycle engine
12x6 for .60
- 4 cycle engine
12x7 for .70
- 4 cycle engine
13x6 for brushless Motor.
.46 ~ .50 - 2 cycle
!
Take particular care here
Apply cyano glue
CA
EMERGENCY
Instruction manual
Servo extension:
300mm long x3 (ailerons - center flap)
500mm long x2 (Flap)
600mm long x2 (Elevator)
700~800 Watt
Brushless Motor.
.60 ~.70 - 4 cycle
Hatched-in areas:
remove covering
film carefully
Assemble left and right
L/R
sides the same way.
Silicone tube
Li-Po Battery, 14.8V, 4000mAH, 80A
Low setting
Check during assembly that these
parts move freely, without binding
Not included.
X
These parts must be
purchased separately

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F-82 TWIN MUSTANG and is the answer not in the manual?

Questions and answers

Summary of Contents for VQ Model F-82 TWIN MUSTANG

  • Page 1 Radio control model EMERGENCY SPECIFICATIONS Wingspan 2100mm Length 1240mm Instruction manual Electric Motor 800 Watt Glow Engine .46 2-T / .70 4-T Radio 8 Channels / 11 Servos REQUIRED FOR OPERATION (Purchase separately) 10.5x6 for .40 - 2 cycle engine Silicone tube 11x6 for .46 - 2 cycle engine...
  • Page 2 1-WING BOTTOM-VIEW Thin CA ......1 Connector.....1 2x170mm rod..1 2 mm Steel clevis...1 Thin CA Push the wooden dowel to the Wooden dowel..4 hole up to the center line Thin CA DO THE SAME WAY WITH FIXED LANDING GEAR OTHER SIDE ASSEMBLY Main landing gear...
  • Page 3 Note: In case your E-retracts can not open (to extended position) after closed (retracted position). Please make sure 2-WING your E-retract wasn’t stuck when it close. Stuck, this problem maybe from the struts, when E-retract close, the body of the struts, it touch to the body of E-retract and it make the E-retracts can’t close 100%, or maybe the wheel touch to the edge of the wing or plastic cover.
  • Page 4 3-WING Carefully, slide the aluminum tube throughout the center wing with A=B as shown.
  • Page 5 4-WING 300mm servo extension (not included) 500mm servo extension (not included) Cut away only the covering DO THE SAME WAY WITH OTHER WING Ensure smooth non-binding movement 2 mm Aileron control horn..2 2x30mm....4 Flap control horn...2 2x170mm rod......4 Connector......4...
  • Page 6 5-ENGINE MOUNT - ENGINE 4x25mm screw 3x20mm screw Wooden washer ...4 ....4 ...4 ! Align the mark on both mounts 4mm Blind-nut with the mark on the fuselage 3mm nut ....4 ....4 ! Engine thrust on balk head is already adjust at factory Pull the magnetic battery hatch out of the fuselage B’...
  • Page 7: Electric Motor

    6-FUEL TANK Blow To muffler Water Filler tube Rubber stopper 3x25mm screw To engine 3x35 mm screw After confirming the direction . Insert this assembly, clunk end first, into the fuel Checking for leaks - block the vents and blow tank and tighten and screw the fuel tank cap on firmly.
  • Page 8: Vertical Stabilizer

    8-HORIZONTAL STABILIZER MOUNT RIGHT VERTICAL STABILIZER Securely glue together. If coming off during (Looking from the rear of the fuselage) flight, you lose control of your air plane. Align the horizontal stabilizer mount, then glue the DO THE SAME WAY WITH THE horizontal stabilizer mount onto the fin, using a LEFT VERTICAL STABILIZER generous amount of thin CA to ensure to strong bond,...
  • Page 9: Rudder Control Horn

    10-RUDDER Without using glue yet, push the rudder and its hinges into the hinge slots in trailing edge of the vertical stabilizer. When satisfied with the alignment, apply a thin layer of petroleum jelly on one side of each hinges as shown(16A) Then, apply a thin CA glue on other side of each hinges as shown (16B).
  • Page 10: Tail Wheel

    12-TAIL WHEEL 2x10mm screw FUSELAGE - BOTTOM VIEW 5/64 in.(2mm) I.D collar 1- Insert the tail wheel pushrod into the hole on the tail gear control horn (as show). 2- Install the tail wheel control horn in place. 3- Instal the tail wheel gear in place. 4- Secure the tail wheel control horn in place using a 5/64”(2mm) screw set, 2x10mm screw 2mm I.D collar...
  • Page 11: Elevator Servo

    14-LINKAGES Tail wheel push rod Thrott. servo Rudder servo Rudder push rod Rudder push rod Rudder servo Thrott. servo Tail wheel push rod Tail wheel pushrod (D=1.2mm) 3mm Screw 3mm Screw Rudder pusshrod throttle pushrod D=5/64”(2mm) D=.050”(1.2mm) 2 mm Connector 2 mm ....2 THROTTLE...
  • Page 12 17-COWLING 1/16” 2.5X12mm self tapping screw 1~2mm ....4 Ruler 1/16” 1/16” 1.5mm 1.5mm Cut the opening 2.5x10mm self tapping screw 3-Remove the engine and insert the cowl on to the fuselage so the distance from the fire wall to the front of the cowl is 115mm. Trace around inside the hole on the board or transparent plastic with a pencil.
  • Page 13: Horizontal Stabilizer Installation

    19-HORIZONTAL STABILIZER INSTALLATION Carefully, slide the horizontal stabilizer into the horizontal stabilizer mounting slots. 3x15mm screw When you are satisfied with the alignment, secure the horizontal stabilizer ...4 in place using the four 3x15mm screws 20-CONTROL HORN RIGHT FIN AND FUSELAGE RIGHT FIN AND FUSELAGE Control horn ....2...
  • Page 14: Wings Installation

    21-WINGS INSTALLATION...
  • Page 15 22-WINGS INSTALLATION...
  • Page 16 22-DECAL Fuel cap sticker EMERGENCY Sticker Fuel cap sticker Navigator sticker Pilot LT Col. BOB THACKER EMERGENCY FLIGHT TEST DIVISION A.M.C WRIGHT FIELD DAYTON. OHIO Pilot 1ST LT. JOHNNY ARD FLIGHT TEST DIVISION A.M.C WRIGHT FIELD DAYTON. OHIO EMERGENCY 23-BALANCE - CONTROL SURFACE Note: If necessary, move the battery pack or add weight to either 3-5/64”...
