VQ Model A26K COUNTER INVADER Assembly Instructions Manual page 4

3.Engine / Motor
In case of
4-cycle engine
Viertaktmotoren
Mark
In case of 2-cycle
engine
Zweitaktmotoren
Mark
4-Fuel tank /
Kraftstofftank
1
To muffler/ Überlauf
Tanken
Filler tube /
Rubber stopper
To engine
zum Motor
3x35mm screw / schraube
After confirming the direction . Insert this
2
assembly, clunk end first, into the fuel tank
and tighten and screw the fuel tank cap on
firmly.
Überlauf
zum Motor
3x35 mm screw
3
3mm
1/8"
X
Tanken
Filler tube /
4mm
Blow
Water
Note: Apply Silicon sealer to
each of the screw and nut.
6
- Reposition the engine on the engine mount beams, aligning it with
the holes. Secure the engine to the engine mount using four
1/8x51/64"(3x25mm) screws.
Filler tube
Tanken
Checking for leaks - block the vents and blow into
the feed - if in doubt submersing the tank in a blow
of water will show up any problems.
1 2 3
Foam
WING - TOP VIEW / AUFSICHT
L/R
