■5. Terminal Setting
Mode levels
The Terminal Setting mode is composed as shown in the diagram below.
Mode
Contrast The contrast the LCD display is set in 9 stages (0 to 8).
Bright The brightness of the LCD display is set in 5 stages (0 to 4).
Key Sound The button click sound volume is set in 5 stages (0 to 4).
The time until the unit goes into POWER SAVE mode when no button
PowerSave operation is performed is set 5 stages (OFF, 1 min., 3 min., 7 min. and
10 min.).
Default All of the settings above are returned to the default settings.
Password Change Change the password. (Refer to page 48)
1. Select [5. Terminal Setting] and press the
2. Selects items with the
3. Changes the setting with the
4. When the button is pressed, the setting will become
valid.
5. Press the button to return to the mode selection
screen.
Outline
-47-
button.
and buttons.
and buttons.
Default setting
4
2
2
1M
-
0000
No.EX※※-OML0011-C
