■3. Sys. Configuration
Mode levels
The system operation setting mode is composed as shown in the figure below.
Mode
1. Tag Input
2. Re Register
3. Hold/Clear
4. Clr Counter Value
5. Parameter Default
6. Clear Error Log
1. Select [3. Sys. Configuration] and press the
2. Enter the password.
3. Select items with the
button.
The tag name of the unit is compiled. (Refer to page 28)
The structure memory information of the unit is updated.
(Refer to page 29)
This mode is used to select whether the Hold/Clear function is set by the
switch on the SI unit or by the Handheld Terminal. (Refer to page 30)
The ON/OFF counter value of each unit is cleared. (Refer to page 31)
Parameters of each unit are reset to the default values.
(Refer to page 32)
All error logs are cleared. (Refer to page 32)
-27-
and buttons and press the
Outline
No.EX※※-OML0011-C
button.
