•Forced input and output screen of the Analog unit
♦Explanation of screen
a) Displayed unit symbol (Refer to page 52)
b) Tag name (Refer to page
c) Manifold number/Unit number (Refer to page 16)
d) Channel number
e) Channel selection cursor
f) Select the channel with the
g) Display mode switch symbol
1. Select the channel with the
input selection screen.
2. An underline is displayed under the digits to be input.
The underline is shifted to the digits to be set with the
Values and ± are changed with the
3. Press the button to fix the value and return the screen to the previous 53.
4. Select the button [Set] or
Set: Fix the data selected and send it to the unit.
Cancel: Reset all the forced input and output data to the current value.
28)
and buttons.
and buttons and
buttons.
and
button [Cancel].
-22-
button pressed, the screen shifts to the value
and buttons.
No.EX※※-OML0011-C
