3. Error log indication
The errors that have been generated are displayed in order from the top.
♦Explanation of screen
a) Error log number
b) Manifold number/Unit number (Refer to page 16)
c) Channel number
d) Displayed unit symbol (Refer to page 52)
e) The next error log is displayed with the
f) h: hour, m: minute, s: second
The time elapsed from when the power supply was applied until the time when error was generated is
displayed.
When the power supply of the SI unit is turned off, the time is reset.
g) Error code (Refer to page 51)
h) Error code details (Refer to page 51)
and buttons.
