■Definition and terminology

Terminology
C
Channel number
D
Diagnostic
E
Error log
Enforced output function
Enforced input function
H
Handheld Terminal
(H.T.)
M
Manifold number
O
ON/OFF counter
P
Parameter copy function
Power save
S
SI unit
T
Tag
U
Unit number
Sequential number given to each input and output on an individual module
(Refer to the manual of each unit for the arrangement of the channels).
Number given for each unit's input and output point. Please refer to the manual
of each unit for the arrangement of the channel.
Function of EX600 to self monitor if error has occurred or configuration has
changed.
A chronological list of previous errors occurred. A maximum of 30 errors can be
recorded.
A function to drive an output signal forcibly, ignoring control data from the PLC.
A function to specify an input signal forcibly, ignoring signal from the connected
sensor.
Connected to the dedicated connector of the SI unit to adjust the internal
parameters, monitor the status of all input and output signals, and turn on input
and output forcedly.
The number of the EX600 manifold that includes the selected unit. This function
will be utilized in the future. Until then, the current state will always be 0.
Counter of number of times when output or input changes from OFF to ON.
Function to copy selected unit parameter setting to all units in the manifold or
also to copy channel parameter to all channels in the same unit.
The LCD's backlight is turned off to save power.
Abbreviation of serial interface unit. A unit connected to a PLC to communicate
input and output data.
An electronic, 4 character name that can be given to units. This name can help
with unit management. Electronic name can be given to manage units. Each
unit can be given maximum of 4 digits of character.
Selected unit's number. Unit connected right of the end plate becomes unit
number 0.
-9-
Definition
No.EX※※-OML0011-C
