SMC Networks EX600-HT1A Operation Manual page 42

4. Channel parameter setting
7. Press the button.
Copy is completed, and the screen returns to the channel parameter selection screen.
1. Press the on the parameter selection screen.
Or select the parameters where the [channel] in the
[object] is selected, and press the
2. Select the channel and press the
When the button is pressed, the information is
updated.
When the button is pressed, the screen shifts to
the screen that displays error/counter values.
3. Enter the password.
4. Select the parameter with the
press button.
(Refer to Channel parameter setting for the details of
setting. (page 42 to 46))
5. Select the setting value with the
buttons and press
6. Press the button to complete the setting.
To copy the set value to channels of the same type in
the unit, press the
-41-
button.
button.
and buttons and
, , and
button.
button.
No.EX※※-OML0011-C
