When you execute RAID 1, RAID 5, or RAID 6 configuration, the system will initialize the
hard drives, create the RAID device, format the RAID device, and mount it as a volume
on the NAS. The progress will be shown on the LCD panel. When it reaches 100%, you
can connect to the RAID volume, for example, create folders and upload files to the
folders on the NAS. In the meantime, to make sure the stripes and blocks in all the RAID
component devices are ready, the NAS will execute RAID synchronization and the
progress will be shown on "Storage Manager" > "Volume Management" page. The
synchronization rate is around 30-60 MB/s (varies depending on the hard drive models,
system resource usage, etc.)
Note : If a member drive of the RAID configuration was lost during the
synchronization, the RAID device will enter degraded mode. The volume data is still
accessible. If you add a member drive to the device, it will start to rebuild. You can
check the status on the "Volume Management" page.
To encrypt the disk volume*, select "Yes" when the LCD panel shows <Encrypt Volume?
>. The default encryption password is "admin". To change the password, login the NAS
with an administrator account and change the settings in "Storage Manager" >
"Encrypted File System".
E n c r y
Y e s
When the configuration is finished, the NAS name and IP address will be shown. If the
NAS fails to create the disk volume, the following message will be shown.
C r e a t
R A I D 5
*This feature is not supported by TS-110, TS-119, TS-210, TS-219, TS-219P, TS-410,
TS-419P, TS-410U, TS-419U, TS-119P+, TS-219P+, TS-419P+, TS-112, TS-212, TS-
412, TS-419U+, TS-412U.
Data encryption functions may not be available in accordance to the legislative
restrictions of some countries.
V ie wing Sy ste m Inform a tion on LC D Pa ne l
When the LCD panel shows the NAS name and IP address, you can press "Enter" to go to
p t V o
N o
i n g . .
F a i l
l u m e ?
.
e d
