C Error Messages

TR-MARK III is designed to be trouble free, so you may not see many error messages. A few
messages appear because of operation error. Let's have a look at those first.
Message
No Test Leads:
Emergency Pressed:
Check Trafo Setup:
TRex not found:
3P:3P only with Voltage Ext:
Overcurrent:
Other messages may appear because of damage or malfunction of a component of
TR-MARK III. If one of those messages appear, swicht TR-MARK III off. Restart it after a few
seconds and try again. If you are still facing the same message, please contact our local
representative or call Raytech Switzerland.
Calibration failed
•
Calib Warning
•
ADC Quarz failed
•
No Sync
•
No Com
•
H8Reset
•
Comm Lost
•
90100.1.02 Instruction Manual TR-MARK III
Explanation
TR-MARK III will find out if no test leads are connected, or if
they are not connected to test object. This message my
save time during measurements in the field.
No measurement is started when emergency switch is
pressed, a running measurement will be cancelled
immediately. Release emergency switch, and this message
will disappear.
In many cases an incorrect connected test object is
detected by TR-MARK III. Then this message appears.
You will see this message, when trying to measure with a T-
Rex which is not connected.
Another message, that may appear when trying to start a T-
Rex measurement without having it properly connected
As the message says, a too high current is flowing on the H
side. Check test setting, and all connections.
