10.3 TR-MARK III Communication Port

NOTE
⇒ TR-MARK III communication interface is designed to work properly

10.3.1 Hardware Protocol

9 pole D-Sub
•
Pin 2 TXD Data TRSpy to Computer
•
Pin 3 RXD Data Computer to TRSpy
•
Pin 7 GND
•
+/- 12 V Signals
•
Protocol: 19200 Baud, 8 Bit, 1 Stop bit, no parity

10.3.2 Software Protocol

NOTE
⇒ Required firmware version 3.0.28.9 and later. Do not use former
10.3.2.1 Switch to Remote
The Device is switched to REMOTE by:
Command "RM"
-
Every command which is executing a measurement (MA,MB,MC,MF )
-
10.3.2.2 Switch to Local
With Command SL ( Set to Local) or with the Local Button on the display. This button will be
the only object on screen in remote mode until it is pressed, or 'local' command is sent.
90100.1.02 Instruction Manual TR-MARK III
with the same hardware and command set as TR Spy II.
Commands that are not used on TR-MARK III will return 'ok' as
Answer.
Versions for Remote Control. Call us for updates.
Page 50 of 70
