A.A.D Operating TR-MARK III with T-Rex
NOTE
⇒ To activate a properly connected T-Rex, all you must do is choose
WARNING!
⇒ BEFORE OPERATING THIS OR ANY OTHER TEST EQUIPMENT
⇒ DO NOT VARY INPUT VOLTAGE (MAINS) AFTER POWERING ON
Quick Start Guide
1. Setup T-Rex and MARK-III.
Switch on the instrument.
Touch 'New', then 'New Transformer
to create a new '3P' transformer.
3. Press 'Go ABC' or 'Go...' to
start measurement.
T-Rex operation is indicated by
Ut=Extern
90100.1.02 Instruction Manual TR-MARK III
"3P" when creating a new Transformer.
READ ALL SAFETY WARNINGS AND UNDERSTAND THEM FULLY.
TEST SET.
2. Choose '3P' and '0' for transformer
type. Then press 'GO'
4. Get the results
Page 58 of 70
