6 Operation Elements Rack

Please find legend of elements on previous page.

3: Emergency Stop

1: Fuse and

Mains Input

5: Low Voltage Side

2: Ground Terminal

90100.1.02 Instruction Manual TR-MARK III

10: Display and

Touch Panel

4: High Voltage Side

1 Mains Switch

9: Safety

8: Interface (USB)

Indicator

7: External

(Tap Changer)

6: 3 Phase

Extension

(T-REX)

8: Interface

(USB and RS232)

Page 17 of 70
