8.1.3 Operating on an advanced Screen, Transformer Data entered

NOTE
⇒ Please Check chapter '8.3 Info' if you are not familiar with entering and
8.1.3.1 Pass, Fail and Transformer Name
When in 'Info' Rated Voltage Data are entered, Results are automatically checked. An
indication for pass or fail is displayed for each phase. To provide more details, deviation
appears in column Dev.
In chapter '8.3 Info', read about section 'General' for details about pass/fail criteria.
Pass:
When a Transformer Name is
entered, it is displayed here
90100.1.02 Instruction Manual TR-MARK III
editing Transformer Data. Using Transformer Data may offer several
benefits to you.
Fail:
