PM0075
3.4
Flash status register (FLASH_SR)
Address offset: 0x0C
Reset value: 0x0000 0000
31
30
29
15
14
13
Bits 31:6 Reserved, must be kept cleared.
Bit 5 EOP: End of operation
Note: EOP is asserted at the end of each successful program or erase operation
Bit 4 WRPRTERR: Write protection error
Bit 3 Reserved, must be kept cleared.
Bit 2 PGERR: Programming error
Note: The STRT bit in the FLASH_CR register should be reset before starting a programming
Bit 1 Reserved, must be kept cleared
Bit 0 BSY: Busy
28
27
26
25
12
11
10
9
Reserved
Set by hardware when a Flash operation (programming / erase) is completed. Reset by
writing a 1
Set by hardware when programming a write-protected address of the Flash memory.
Reset by writing 1.
Set by hardware when an address to be programmed contains a value different from
'0xFFFF' before programming.
Reset by writing 1.
operation.
This indicates that a Flash operation is in progress. This is set on the beginning of a Flash
operation and reset when the operation finishes or when an error occurs.
24
23
22
Reserved
8
7
6
Doc ID 17863 Rev 1
Register descriptions
21
20
19
18
5
4
3
2
WRPRT
PG
EOP
ERR
ERR
Res.
rw
rw
rw
17
16
1
0
BSY
Res.
r
25/31
