Control Element or Group
SWEEP
MAG
PRESET
LINE SEL
Input Selection Buttons
CURSOR
CAPTURE
Up/Down/Left/Right Arrow keys
and SEL Button
General Knob
Vertical and Horizontal Knobs
Display Select/Thumbnail
Power button
HELP
CONFIG
DISPLAY
MAIN
WFM5200 Installation and Safety Instructions
Description
To select how waveform components are displayed and whether lines or fields are shown
To select the magnification setting that you want
To recall the factory preset, save a setup to a preset, recall an existing preset, and clone a
setup between instruments
To toggle Line Select Mode on or off
1A, 1B, 2A, 2B, and EXT REF to select inputs
To measure waveforms with cursors
To capture the display
To traverse between menu panes. Use SEL to set the selected parameter
To select or adjust a parameter and to navigate through a menu
Use to position waveforms when displayed in tiles or full screen. When the Audio tile is active,
use the Horizontal knob to adjust the headphone volume
WARNING.
To prevent risk of hearing damage, always turn down the headphone audio level
before connecting a headphone into the headphone jack. Sound levels and impedance can
vary between headphones.
Default settings set this button as a tile select button, allowing you to quickly move from one tile
to the next when the instrument is in 4-Tile mode. This button can also be set from the MAIN
button menu to display a thumbnail view of the picture in the selected measurement display.
Press to turn power on or off
To display the online help
Access to various configurable parameters, installed options, IP address, system upgrade,
and more
Access to waveform, graticule, and LCD backlight intensity. It also provides access to Infinite
Persistence mode.
Access to tile display mode, display overlay, Multi-Input mode enable, USB status, Multi-Button
function (allows you to configure the Display Select button to turn on and off a thumbnail
view), and Thumbnail on/off.
Front-Panel Controls
