Power-On and Power-Off Procedure

AC Power Requirements
Power-On
Power-Off
WFM5200 Installation and Safety Instructions
This instrument operates from a single-phase power source with the neutral
conductor at or near earth ground. The line conductor is fused for over-current
protection. A protective ground connection through the grounding conductor in
the power cord is essential for safe operation.
The instrument operates from an external AC adapter with a line frequency of 50
or 60 Hz, over the range of 100-240 Volts, without the need for configuration,
except the power cord. (See page 3, International power cords.) The typical
power draw is 27 Watts. Refer to the WFM5200 Specifications and Performance
Verification Technical Reference on the Product Documentation CD for additional
information on power and environmental requirements.
If you are using a battery as a power source, read the battery information provided
in the front of this manual. (See page 10, Battery Power.)
1. Connect the supplied power cord to the rear-panel power connector. If you are
using a battery, connect the battery as explained in the installation instructions
that come with the battery.
2. Press the power button on the instrument front-panel and the instrument will
turn on.
NOTE.
The Standby button on the front-panel does not disconnect mains power.
Only the power cord at the rear of the product can disconnect mains power.
Make sure that the power cord is accessible when the product is operating.
1. Press the power button on the instrument front-panel to turn the instrument off.
2. To remove power completely, disconnect the power cord from the rear-panel
of the instrument.
