Robustel R2000 dual Installation And Configuration Quick Manual page 14

Robustel GoRugged R2000 Dual Quick Guide
4. After logging in the R2000 Dual, the home page of the R2000 Dual router's web interface is displayed, as the
screenshot below.
This section allows users to save configuration, reboot router, logout. When the R2000 Dual is logging in at the
first time, there will be a pop-up tab "
to close the pop-up tab.
Item
Save & Apply
Reboot
Logout
RT_QG_R2000 Dual_v.1.0.2
Confidential
Description
Click to save the current configuration into router's flash and apply
the modification on every configuration page, to make the
modification taking effect.
Click to reboot the router. When the Reboot button is in yellow, it
means that some completed configurations will take effect only by
reboot.
Click to exit safely, then it will switch to login page. Shut down web
page directly without logout, the next one can login web on this
Control Panel
11.11.2016
", click
Button
14/21
