Chapter 3 Initial Configuration

The router can be configured through your web browser including IE 8.0 or above, Chrome and Firefox, etc. And the
supported operating systems are: Linux, Mac OS, Windows 98/NT/2000/XP/Me/Vista/7/8, etc. There are various
ways to connect to the router, either through an external repeater/hub or to PC directly. However, make sure that
your PC has an Ethernet interface properly installed prior to connecting the router. You must configure your PC to
obtain an IP address through a DHCP server or a fixed IP address that must be in the same subnet as the router. If you
encounter any problems accessing the router web interface it is advisable to uninstall your firewall program on your
PC, as this tends to cause problems accessing the IP address of the router.
3.1 Configure the PC in Window 7
There are two methods to configure the IP address on PC, one is to obtain IP address automatically from DHCP server,
and another is to configure a static IP address manually within the same subnet of R2000 Dual router.
The configuration for Windows system is similar.
1. Go to Start > Control Panel > Network and Sharing Center, and then double-click Local Area Connection.
