Note:
plane. The distance varies from one adapter type to another and is explained on the
PI-MAX3 outline drawings. For quick reference, the distances are given below.
C-Mount: Mounting face to image plane is factory preset to an optical distance of
Spectroscopy: Mounting face to image plane is factory preset to an optical
F-Mount: Mounting face to image plane is factory preset to an optical distance of
PI-MAX
Each adapter has a preset optical distance from the mounting face to the image
0.690" ±0.010" [17.53 mm ±0.25 mm].
distance of 0.894" ±0.010" [22.71 mm ±0.25 mm].
1.831" ±0.010" [46.50 mm ±0.25 mm].
®
