108
CoolCUBE Circulator
II
Closed loop system
Hoses: CoolCUBE
at the circulator ends and CPC quick disconnects at the camera ends. Requires PI kit.
Coolant: 50:50 ethylene glycol and water at 23°C
Dimensions: Refer to Appendix B, "Outline Drawings", page 113
Circulator Weight (Filled): 6.0 lbs (2.7 kg)
Hose Weight (Filled): 3.0 lbs (1.4 kg) per hose

Computer

The GiGE Ethernet communications interface is used for communication between the
PI-MAX3 camera and the host computer. The minimum computer requirements for the
system are as listed below:

Windows

2 GHz Pentium

1 GB RAM (or greater)

CD-ROM drive

At least one unused PCI card slot (32-bit) (PCI 2.3 compliant 32-bit 33/66 MHz bus)

Super VGA monitor and graphics card supporting at least 65535 colors with at least
128 Mbyte of memory. Memory requirement is dependent on desired display
resolution.

Hard disk with a minimum of 1 Gbyte available. A complete installation of the
program files takes about 50 Mbytes and the remainder is required for data storage,
depending on the number and size of images/spectra collected. Disk level
compression programs are not recommended. Drive speed of 10,000 RPM
recommended.

Mouse or other pointing device.

Operating Environment

Storage Temperature: < 55°C
Lab Temperature: 30°C > T > -25°C
Supplemental Cooling Water Flow Rate: 1-3 liters per minute
Note: Circulating water will enhance cooling performance but is not required.
Lab Humidity: < 80%; non-condensing.
®
PI-MAX 3 System Manual
and PI-MAX3Compatible 1/4" ID, with no-drip quick disconnects
II
® XP (32-bit with SP3 or later) or Vista (32-bit)
® 4 (or greater)
