Specifications
The following specifications are subject to change. Contact the factory or go to
ATTENTION
www.princetoninstruments.com
accessories.

PI-MAX3

CCD type
CCD format
CCD pixel size
Imaging area
Intensifier size
Intensifier type
Phosphor type
Kinetics
Pixel Full Well (min.)
Read Noise (typ.)
*Contact Princeton Instruments for P46 and P47 phosphor availability.
Gating:
Jitter: ~35 ps RMS
Minimum delay from trigger: ~25 ns (without bracket pulse), ~35ns with bracket
pulse
Delay, width granularity: 10 ps.
Repetition Rate: 1 MHz ("full voltage" pulse), not burst length limit
Maximum Repetition Rate (photocathode)
Sustained: 1 MHz in variable mode; 6.25 kHz with bracket
for the latest information on performance, options, and
1024i
Kodak KAI:1003 (interline)
1024x1024
12.8 µm x 12.8 µm
13.1 mm x 13.1 mm (18mm dia.)
18 mm
Gen II, Gen III filmless, or
UNIGEN II
P43, *P46 (optional)
No
130 k eˉ
16 eˉrms @ 4 MHz digitization
30 eˉrms @ 16 MHz digitization
35 eˉrms @ 32 MHz digitization
Table 5. CCD Specifications
Appendix A
1024x256
e2v CCD30-11 (full frame)
1024x256
26 µm x 26 µm
18 mm x 6.7 mm or
25 mm x 6.7 mm
18 mm or 25 mm
Gen II, Gen III filmless, or
UNIGEN II
P43, P46 (optional)
Yes
450 k eˉ
14 eˉrms @ 500 kHz digitization
15 eˉrms @ 1 MHz digitization
22 eˉrms @ 2 MHz digitization
101
