2. Main Features

LVM-170A/171A Monitors contain the following features :
Compatible with varied SDI signals
●
- The product is compatible with varied
SD/HD/3G(A/B)-SDI 480i,576i,720p,1080i/p,
1080psf.
Compatible with analog signals
●
- The product is compatible with analog
signals - CVBS
HDMI/DVI Digital(HDCP) / Analog input
●
support
- HDMI, DVI digital/analog(VGA) input is
available without any other accessories.
All-in-one type system
●
- Slim and all-in-one type monitor that
requires no other accessories and optimized
for space utilization.
Waveform/Vector Scope/Luma(Y') zone
●
check/Audio Level Meter support
- Waveform & Vector Scope support
- Luma(Y') zone check support(False color)
- Embedded Audio Level Meter support
Luma(Y') zone check(Color/Zebra type)/
●
Range error function
Audio in & out
●
- built-in internal speaker (Embedded audio &
External audio in)
- Stereo audio out using phone jack & external
audio in.
Knob Control
●
- Easy to adjust user confi guration using the
control knobs.
BLUE ONLY/MONO/Focus-Assist/H/V delay
●
Internal pattern generator(0~100% Gray/
●
Colorbar+Pluge)
Varied Markers & Safety Areas
●
- Center Marker, Safety Area Marker, Aspect
Marker, Display Size(Scan)
6 Multi Format LCD Monitor
Wide screen compatible
●
- Wide screen for 16:9 aspect monitoring.
AC/DC Compatible
●
- Basically, this product is powered by a
normal AC source, and is also compatible
with DC.
Remote control function
●
- The product can be remotely controlled
using external switch or RS-422
communication.
RS422/UMD feature support
●
- This product supports protocols provided by
TVLogic or a TSL protocol.
Additional Features
●
- Wide Viewing Angle, Loop Through (SDI/
Analog), VESA mounting, Easy to operate
OSD user interface, Rack Mountable Design.
- LVM-170A : 700:1 contrast, 300cd/㎡
Brightness
- LVM-171A : 1500:1 contrast, 450cd/㎡
Brightness
