2. Getting started

Once the instrument is switched on (press
key <I/0>) the main menu is displayed. 6
sub-menus (non visible menus can be
called up while scrolling with the arrow
keys) are listed with the following respec-
tive function:
- Gas analysis : Perform gas analysis
- Draft/Pressure
- Soot...Oil trace
- Data processing : Classify measurements/Load or send data
- Adjustments : Modify instrument adjustments
- Control : Check instrument operation state
To start a measurement select the sub-menu "Comb.measurem."
using the arrow keys and confirm with <OK>. The instrument starts a
1-minute calibration phase and the fuel types selection is displayed.
The following fuel types are selectable:
Fuel types according to 1
Fuel oil (B)
Natural gas (B)
City gas (B)
Coke oven gas (B)
Liquid gas (B)
Use the arrow keys to select the correct fuel
type and confirm with <OK>.
The instrument will then enquire if a data
bank function is requested. If the meas-
urement values should be attributed to a
specific plant, so press <F1> (<F4> = no:
measurement will be made without classifi-
cation).
ecom-CN
