Search word: In case the plant identification is known, so a plant
already recorded can be found out using a search machine.
Select "Search word" and confirm with
<OK>. Input 4 related digits of the plant
identification:
Input example: "25.11" for plant identification 0000001.25.11.99
After input, press <OK> to start the search. All correspondences with
this number get filtered. Use the arrow keys to scroll thru the select-
ed numbers (F1 for selection start, F2 for selection end).
Once the desired data block has been
found, press <OK> to activate and view the
previous measurement performed at this
plant (select „Look at" and confirm with
<OK>).
All measured and calculated values are accessible on screens,
scrollable one after the other with the cursor keys.
Date Time
25.11.99 10:35:56
0000001.25.11.99
Memory number
CO-measur.
O2 17.5 %
CO 0.0% 738 ppm
CO 123 ppm
Lambda 7.00
Gas analysis: keys
Press twice <ESC> and then „ Comb.measurem." <OK> to start
with the next measurement.
ecom-CN
O2
CO2
CO
Lambda
T.Gas
T.Air
Losses
8
Eta
Soot.Oil deriv.
Draft
T.Boilerl
1.Soot meas.
2. Soot meas.
3. Soot meas.
Oil trace
↑↓
!
Search word
Input:
25.11
F1:First
F2:Last
0000001.25.11.99
Memory number
Measurement data
3.2 %
13.1 %
12 ppm
1.18
184 °C
20 °C
7.5 %
92.5 %
-0.08 hPa
65 °C
0.5
0.3
0.7
No
F3:Empty
F4:Edit
8 M
existing
