4.5. Soot...Oil trace
In the sub-menu "Soot.Oil deriv." the measurement values for boil-
er temperature, soot dot number and oil trace can be inputted.
Select the corresponding line on the display and press <OK> to acti-
vate the input. The input for boiler temperature and soot dots 1-9 can
occur one after the other using the instrument keyboard. Press
<OK> to take over the value in the measurement data record. The
result of the oil trace determination can be documented as follows:
- Place cursor on line "Oil trace"
- Use <OK> to adjust result
("No", "Yes" or "- - - ")
Once all necessary inputs have been made, press <ESC> to quit the
menu. The measurement is complete.

5.6. Record and print measurement

After the gas analysis, please transfer the recorded
data (intermediate memory) into the internal
instrument memory otherwise the values will get
Press <Print> (printer symbol) to access
the printing menu. If need be, the recorded
values can be checked again („Look at",
<OK> and scroll with the cursor keys).
If all data are correct, press „Record -> M"
and <OK> to transfer in the internal
memory. A successful transfer is character-
ized by a "M" on the upper right part of the
display.
Page 12
lost by instrument switch-off!
Soot.Oil deriv.
T. Boiler --- °C
1. Soot meas. ---
2. Soot meas. ---
3. Soot meas. ---
Oil trace ---
Print
Look at
Store to memory
↑↓
Select with !
Print
Look at
Store to memory
↑↓
Select with !
ecom-CN
M
