3.1.10 Noise Power
3.1.10.1 Transmit Band
3.1.10.2 Receive Band (3.7 to 4.2 GHz)
3.1.11 Group Delay, any 40 MHz
3.1.11.1 Linear
3.1.11.2 Parabolic
3.1.11.3 Ripple
3.1.12 Residual AM Noise
3.1.13 Phase Noise profile
3.1.14 Spurious Signals
3.1.14.1 Spurious Signals, spectral limits
3.1.14.2 Power Line Related, individual
3.1.14.3 Power Line Related, sum of all
3.1.14.4 Spurious Signal, Out of band, max
3.1.15 VSWR
3.1.15.1 Input
3.1.15.2 Output
3.1.16 Prime Power
3.1.17 Serial Interface
3.1.17.1 RS-232
3.1.17.2 RS-422/485 (4-Wire Mode or
T HI S DOCUME NT I S T HE P ROP E RT Y OF XI COM T E CHNOLOGY. RE P RODUCT I ON OR RE LE AS E WI T HOUT E XP RE S S P E RMI S S I ON I S S T RI CT LY P ROHI BI T E D.
XTD-400C, 5.85 – 6.425 GHz, RO1
Document No. 305-0386-201
EAR EXPORT CONTROLLED: The information contained in this Manual refers or relates to a product that is subject
to the U.S. Export Administration Regulations (EAR). Transfer of data herein by any means to a Foreign Person,
whether in the U.S. or abroad, may require an export license from the U.S. Department of Commerce.
2-Wire Mode)
-70 dBw/4KHz max
-150 dBw/4KHz max
0.01 nS/MHz max
0.005 nS/MHz
0.5 nS/Pk-Pk max
-50 dBc fm 10 Hz to 10 KHz max
-20(1.5+Log(Freq)) dBc fm 10 KHz to 500 KHz max
-85 dBc above 500 KHz max
10 dB below IESS phase noise
-37 dBc 10 to 10,000 Hz max
-20(1.5 + log(f))+13 dBc 10 KHz to 100 KHz max
-60 dBc above 100 KHz max
-50 dBc
-47 dBc
-60 dBc
1.6:1 max
1.3:1 max
100-260 VAC
1550 VA max
0.95 Power factor min
47 to 63 Hertz
Single Phase
Monitor and Control
Monitor and Control
2
max
