Fault Log
Entry
HelixArc Heater Fault
HelxArc2 Momentary Helix Arc Fault on
2nd TWT in dual tube units
Hi Drv A Input Drive High Alarm:
Software Power Limit,
Constant Power
Hi Temp Over Temperature Fault from
thermocouple
Hi Temp2 Over Temperature Fault from
second thermocouple. (Dual
TWT units only)
