Unpacking and Installation

Unpacking and Inspection

Inspect the inside and outside of the shipping container for signs of
damage. If any shipping damage is detected, call the shipping carrier and
submit a damage report.

Unpacking

Compare the packing list to the contents of the container to be certain that
all enclosed material has been received. Save all data sheets. They will
be useful during any maintenance actions. Save the shipping container
and packing material and use it if you need to reship the unit.

Inspection

Inspect all items for any damage received during shipment. If shipping
damage is detected, submit a damage report to the shipping carrier.
Failure to submit a report may invalidate any future claims.

Mechanical Installation

Some units have mounting brackets supplied to mount the amplifier.
Refer to the appendix titled Mechanical Drawings.
When performing the procedures in this section refer to the Outline
Drawings and Interconnect Drawings for your specific amplifier. These
drawings are located in appendices titled Mechanical Drawings and
Interconnect Drawings respectively.

Environmental Information

The ODU is designed for outdoor installation. The ODU enclosure meets
IPX4 protection level.
