Motion Control Engineering 2000 Manual page 161

Table 5.14 Controller Board CTL A Processor Diagnostics
Address
Port C inputs:
01 = (n/a)
02 = PHE
03 = MCSB
04 = MGBR
05 = FRSA
06 = (n/a)
07 = (n/a)
102 08 = (n/a)
09 = (n/a)
10 = (n/a)
11 = (n/a)
12 = (n/a)
13 = (n/a)
14 = (n/a)
15 = (n/a)
16 = (n/a)
Port D inputs:
01 = SAFSD
02 = CSBA
03 = SAFLD
04 = DZLV
05 = ABGA
06 = GBR
07 = MREN
103 08 = INCT
09 = INCTU
10 = INN
11 = HDB
12 = HDBR
13 = ABTA
14 = TAB
15 = BAB
16 = ABGRA
Port E inputs:
01 = MABB
02 = DCAB
03 = MDLR
04 = MGSR
05 = FCCC
06 = FCS
07 = FCOFF
104 08 = HLD
09 = (n/a)
10 = (n/a)
11 = (n/a)
12 = (n/a)
13 = (n/a)
14 = (n/a)
15 = (n/a)
16 = (n/a)
F5: Controller Utilities/Monitoring and Reporting
