Motion 2000 TSSA Description
The job prints accompanying your Motion 2000 controller are the primary document necessary
to install the controller and additional equipment (if ordered from MCE). The job prints and
this manual together provide the information necessary to install, adjust, and troubleshoot the
Motion 2000 elevator controller. Study the job prints and read the manual before installing and
adjusting the controller. Call Motion Control Engineering with any questions you may have
before beginning installation or start-up.
Your Motion 2000 system may include:
• Car controller: Distributed-processor, elevator control configured according to a customer
job survey.
• Car top station: Interface/interconnect/control box between car-mounted equipment and
the car controller.
• Car top junction box: Some jurisdictions require that circuit boards normally mounted
inside the Car top station be mounted in the car controller cabinet instead. In these
instances, the less complex car top junction box is used in place of the car top station.
• Car station: Car operating panel interface.
• Dispatcher: If the car is part of a group, dispatching components and software may be pro-
vided.
Motion 2000 provides:
• Low-rise hydraulic building application
• Performance up to 200 feet per minute
• Up to 32 single or double-openings
• Simplex, duplex or group control
• Extensive field programmability
Maximum car speed
Configuration
Landings
Motor control
Landing system
System access
Dispatching
Environment
Standard enclosure
Optional enclosure
(feature dependent)
Input
1-2 Manual # 42-02-1P21
Motion 2000 Hydraulic Controller Specifications
200 fpm, 1.0 mps
Simplex, Duplex, Group
Up to 32
Solid State, Y - Delta or Across the Line
LS-QUTE (solid tape/magnets), LS-STAN (vanes), LS-EDGE
LCD and switches, hand-held user interface or PS/2 keyboard
Groups to six cars
o o
32-104 F, 0-40
harsh environment rugged service available (NEMA 4, 4X, 12)
34" w x 31.5" h x 11" d (864 x 800 x 380 mm) includes knock-outs
36" w x 42" h x 9" d (914 x 1067 x 305 mm) includes knock-outs
208-600 VAC, 50/60 Hz, single or 3-phase
C, humidity non-condensing up to 95%;
